ASROCK 410M-H M.2 SE
The ASRock H410M-H M.2 SE is a reliable micro-ATX motherboard supporting 10th Gen Intel Core processors, DDR4 memory, PCIe 3.0, and high-speed M.2 storage. It delivers stable performance, essential connectivity, and durability.
Features
Overview
The ASRock H410M-H M.2 SE is a dependable micro-ATX motherboard designed to deliver stable performance and essential features for everyday computing. Built on the Intel H410 chipset, it supports 10th Gen Intel Core, Pentium Gold, and Celeron processors, making it ideal for cost-effective desktop builds with reliable functionality.
Key Features & Specifications
Processor Support
-
Supports 10th Gen Intel Core, Pentium Gold, and Celeron processors
-
LGA 1200 CPU socket
-
Intel Turbo Boost 2.0 Technology support (depends on CPU)
Power Design
-
6-phase power design for stable CPU operation
-
Solid capacitors for durability and consistent power delivery
Memory
-
2 x DDR4 DIMM slots, dual-channel memory architecture
-
Supports up to 64GB DDR4 memory
-
Memory speeds up to 2933 MHz (Intel Core i9/i7) and 2666/2400 MHz (Core i5/i3/Pentium/Celeron)
-
Intel XMP support for memory overclocking
Expansion Slots
-
1 x PCIe 3.0 x16 slot (for graphics cards)
-
1 x PCIe 3.0 x1 slot for expansion cards
Storage Options
-
1 x Ultra M.2 slot (PCIe Gen3 x4/SATA3) for NVMe SSDs
-
4 x SATA3 ports supporting RAID 0, 1, 5, and 10
Connectivity
-
Gigabit LAN (Realtek RTL8111H) for stable wired networking
-
USB ports:
-
Rear: 2 x USB 3.2 Gen1, 4 x USB 2.0
-
Front: Headers supporting additional USB 3.2 Gen1 and USB 2.0 ports
-
-
Video outputs: HDMI, D-Sub for integrated graphics support
Audio
-
7.1 CH HD Audio (Realtek ALC887/897 Codec)
-
ELNA audio capacitors for reduced noise and improved clarity
BIOS & Software
-
ASRock UEFI BIOS with user-friendly interface
-
Features include Instant Flash, Internet Flash, and full hardware monitoring
-
ASRock utilities for driver updates and easy system management
Cooling & Build Quality
-
All-solid capacitor design for longevity
-
Multiple fan headers with smart fan speed control
-
High-density glass fabric PCB to protect against humidity and electrical shorts
Form Factor & Aesthetics
-
Micro-ATX form factor (22.6 cm x 18.8 cm) for compact PC builds
-
Clean black PCB layout with labeled connectors for easy assembly
Specifications
| CPU | SUPPORTS 10TH GEN INTEL CORE PROCESSORS ( SOCKET1200) , 5 POWER PHASE DESIGN , SUPPORTS INTEL TURBO BOOST MAX 3.0 TECHNOLOGY |
|---|---|
| CHIPSET | H370 |
| MEMORY | DUAL CHANNEL DDR4 MEMORY TECHNOLOGY , 2 X DDR4 DIMM SLOTS , SUPPORTS DDR4 2933/2800/2666/2400/ 2133 NON- ECC , UN BUFFERED MEMORY , SUPPORTS ECC UDIMM MEMORY MODULES ( OPERATE IN NON-ECC MODE) MAX. CAPACITY OF SYSTEM MEMORY: 64GB , SUPPORTS INTEL EXTREME MEMORY PROFILE (XMP) 2.0 |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | PCIE X1 GIGABIT LAN 10/100/1000 MB/S , 1 X REALTEK RTL811H , SUPPORTS WAKE-ON-LAN , SUPPORTS ENERGY EFFICIENT ETHERNET 802.3az , SUPPORTS PXE. NO/ NO |
| AUDIO | 7.1 CH HD AUDIO (REALTEK ALC897 AUDIO CODEC ) , SUPPORTS SURGE PROTECTION |
| EXPANSION SLOTS | 1 X PCI EXPRESS 3.0 X16 SLOT , 1 X PCI EXPRESS 3.0 X1 SLOT , 1 X M.2 SOCKET (KEY E) , SUPPORTS TYPE 2230 WIFI/BT PCIeWIFI MODULE |
| STORAGE INTERFACES | 4 X SATA3 6.0 GB/S CONNECTORS , SUPPORTRAID ( RAID 0 , RAID 1, RAID 5 , RAID 10, INTEL RAPID STORAGE TECHNOLOGY 15) , NCQ, AHCI AND HOT PLUG , 1 X ULTRA M.2 SOCKET (M2_1), SUPPORTS M KEY TYPE 2260/2280 M.2 SATA3 6.0 GB/S MODULE AND M.2 PCI EXPRESS MODULE UP TO GEN3 X4 (32GB/S) |
| INTERNAL I/O CONNECTORS | SPI TPM 2.0 IC , 1 X COM PORT HEADER , 1 X CHASSIS INTRUSION AND SPEAKER HEADER , 1 X CPU FAN CONNECTOR (4-PIN) , 1 X CPU/WATER PUMP FAN CONNECTOR ( 4-PIN ) ( SMART FAN SPEED CONTROL ) , 2 X CHASSIS/WATER PUMP FAN CONNECTORS (4-PIN) (SMART FAN SPEED CONTROL) , 1 X 24 PIN ATX POWER CONNECTOR , 1 X8 PIN 12V POWER CONNECTOR , 1 X FRONT PANEL AUDIO CONNECTOR , 2 X USB 2.0 HEADERS ( SUPPORT 3 USB 2.0 PORTS) ( SUPPORTS ESD PROTECTION) , 2X USB 3.2 GEN1 HEADERS ( SUPPORT 4 USB 3.2 GEN1 PORTS ) (SUPPORTS ESD PROTECTION ) |
| BACK PANEL CONNECTORS | 2 X ANTENNA MOUNTING POINTS , 1 X PS/2 MOUSE/ KEYBOARD PORT , 1 X D-SUB PORT , 1 X DISPLAYPORT 1.2 , 1 X HDMI PORT , 2 X USB 2.0 PORTS( SUPPORTS ESD PROTECTION) , 4 X USB 3.2 GEN1 PORTS ( SUPPORT ESD PROTECTION) 1 X RJ-45 LAN PORT WITH LED (ACT/LINK LED AND SPEED LED) , HD AUDIO JACKS : LINE IN / FRONT SPEAKER / MICROPHONE |
| SIZE | |
| UNIQUE FACTORS | ASROCK SUPER ALLOY , PREMIUM 50A POWER CHOKE , SAPPHIRE BLACK PCB , HIGH DENSITY GLASS FABRIC PCB , ASROCK AUTO DRIVER INSTALLER , ASROCK ULTRA M.2 ( PCIe GEN3 X4 & SATA3 ) , ASROCK FULL SPIKE PROTECTION ( FOR ALL USB , AUDIO ,LAN PORTS ) |
