ASROCK B760 PRO RS DDR4 WIFI
The ASRock B760 Pro RS DDR4 WiFi is an ATX motherboard supporting 12th/13th Gen Intel processors, DDR4 memory, PCIe 4.0, fast M.2 storage, and built-in WiFi—offering stable performance and strong connectivity for modern PC builds.
Features
Overview
The ASRock B760 Pro RS DDR4 WiFi is a high-performance ATX motherboard designed for gamers, creators, and power users seeking stability, expandability, and value. Based on the Intel B760 chipset, it supports 12th and 13th Gen Intel Core processors, combining advanced connectivity, robust power delivery, and high-speed networking with a professional, understated aesthetic.
Key Features & Specifications
Processor Support
-
Supports 12th & 13th Gen Intel Core, Pentium Gold, and Celeron processors
-
LGA 1700 CPU socket
-
Intel Turbo Boost Technology support (depends on processor)
Power Design
-
12+1+1 power phase design with premium components for stable power delivery
-
Dr.MOS for improved thermal efficiency and consistent voltage output
-
High-density power connectors and durable PCB for enhanced longevity
Memory
-
4 x DDR4 DIMM slots, dual-channel memory architecture
-
Supports up to 128GB DDR4 memory
-
Memory speeds up to 5333+ MHz (OC)
-
Intel XMP 2.0 profile support for easy memory overclocking
Expansion Slots
-
1 x PCIe 4.0 x16 slot with Steel Slot reinforcement for GPUs
-
1 x PCIe 3.0 x16 slot (x4 mode)
-
1 x PCIe 3.0 x1 slot for additional expansion cards
Storage Options
-
3 x Hyper M.2 slots (PCIe Gen4 x4) for ultra-fast NVMe SSDs
-
4 x SATA3 ports supporting RAID 0, 1, 5, and 10
-
Full M.2 heatsink coverage to maintain optimal SSD temperatures
Networking & Wireless
-
Dragon 2.5Gb LAN for high-speed wired networking
-
WiFi 6E (802.11ax) with Bluetooth 5.3 for fast wireless connectivity and low-latency gaming
USB & I/O Connectivity
-
Rear I/O:
-
1 x USB 3.2 Gen2x2 Type-C
-
2 x USB 3.2 Gen2 Type-A
-
4 x USB 3.2 Gen1 ports
-
-
Front panel headers for additional USB 3.2 Gen1/Gen2 and USB 2.0 support
-
HDMI and DisplayPort outputs for integrated Intel UHD Graphics
Audio
-
7.1 CH HD Audio (Realtek ALC897/ALC1220 Codec depending on batch)
-
Nahimic Audio technology for improved sound quality and immersive gaming experiences
Cooling & Thermal Design
-
Comprehensive VRM heatsinks with extended surface area
-
High-density thermal pads for improved heat transfer
-
Multiple PWM/DC fan headers with full BIOS and software control
BIOS & Software
-
ASRock UEFI BIOS with user-friendly EZ Mode and advanced tuning
-
ASRock utilities for system monitoring, driver installation, and network optimization
-
ASRock Polychrome RGB Sync for customizable lighting effects and control of RGB devices
Form Factor & Aesthetics
-
ATX form factor (30.5 cm x 24.4 cm)
-
Professional black and silver PCB design with subtle RGB accents
-
Reinforced build quality with steel slots and premium components
Specifications
| CPU | SUPPORTS 14TH, 13TH & 12TH GEN INTEL CORE PROCESSORS (LGA1700) , SUPPORTS INTEL HYBIRD TECHNOLOGY , SUPPORTS INTEL TURBO BOOST MAX 3.0 TECHNOLOGY , SUPPORTS INTEL THERMAL VELOCITY BOOST (TVB) , SUPPORTS INTEL ADAPTIVE BOOST TECHNOLOGY (ABT) |
|---|---|
| CHIPSET | B760 |
| MEMORY | DUAL CHANNELS DDR4 MEMORY TECHNOLOGY , 4 X DDR4 DIMM SLOTS , SUPPORTS DDR5 NON-ECC, UN-BUFFERED MEMORY UP TO 5333+ (OC) MAX. CAPACITY OF SYSTEM MEMORY PROFILE : 128GB , SUPPORTS INTEL EXTREME MEMORY PROFILE (XMP) 2.0 |
| LAN + WIFI + BLUETOOTH | 2.5 GIGABIT LAN 10/100/1000/2500 MB/S , DRAGON RTL8125BG , SUPPORTS DRAGON 2.5 LAN SOFTWARE , SMART AUTO ADJUST BANDWIDTH CONTROL , VISUAL USER FRIENDLY UI , VISUAL NETWORK USAGE STATISTICS , OPTIMIZED DEFAULT SETTING FOR GAME , BROWSER , AND STREAMING MODES , USER CUSTOMIZED PRIORITY CONTROL , 802.11AX WI-FI 6E MODULE , SUPPORTS IEEE 802.11a/b/g/n/ac/ax , SUPPORTS DUAL-BAND 2X2 WITH EXTENDED 6GHz BAND SUPPORT , 2 ANTENNAS TO SUPPORT 2 (TRANSMIT) X 2 (RECEIVE) DIVERSITY TECHNOLOGY , SUPPORTS BLUETOOTH 5.3 + HIGH SPEED CLASS II , SUPPORTS MU-MIMO |
| AUDIO | 7.1 CH HD AUDIO (REALTEK ALC897 AUDIO CODEC) NAHIMIC AUDIO |
| EXPANSION SLOTS | 1 X PCIe 5.0 X 16 SLOT (PCIE1), SUPPORTS X16 MODE , 1 X PCIe 4.0 X16 SLOT (PCIE3), SUPPORTS X4 MODE , 1 X PCIe 3.0 X16 SLOT (PCIE4) , SUPPORTS X1 MODE , 1 X PCIe 3.0 x1 SLOT (PCIE2) , 1 X M.2 SOCKET (KEY E) , SUPPORTS TYPE 2230 WIFI/BT PCIe WIFI MODULE AND INTEL CNVio/CNVio2 (INTEGRATED WIFI/BT) , SUPPORTS AMD CROSSFIRE |
| STORAGE INTERFACES | 1 X HYPER M.2 SOCKET (M2_1, KEY M ), SUPPORTS TYPE (2260/280 PCIe GEN4X4 (64GB/S) MODE , 1 X M.2 SOCKET ( M2_2, KEY M) SUPPORTS TYPE 2260/2280 PCIe GEN4X2 (32GB/S) MODE , 1 X HYPER M.2 SOCKET (M2_3, KEY M ), SUPPORTS TYPE 2260/2280 PCIe GEN4X4 (64GB/S) MODE , 4 X SATA3 6.0 GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X eDP SIGNAL CONNECTOR , 1 X SPI TPM HEADER , 1 X POWER LED AND SPEAKER HEADER , 2 X RGB LED HEADERS , 2 X ADRESSABLE LED HEADERS , 1 X CPU FAN CONNECTOR (4-PIN) , 1 X CPU/WATER PUMP FAN CONNECTOR (4-PIN) (SMART FAN SPEED CONTROL) , 5 X CHASSIS/WATER PUMP FAN CONNECTORS (4-PIN) (SMART FAN SPEED CONTROL) , 1 X 24 PIN ATX POWER CONNECTOR , 2 X 8 PIN 12V POWER CONNECTORS ( HI-DENSITY CONNECTOR ) , 1 X FRONT PANEL AUDIO CONNECTOR , 1 X THUNDERBOLT AIC CONNECTOR ( 5-PIN) ( SUPPORTS ASROCK THUNDERBOLT 4 AIC CARD) , 1 X USB 2.0 HEADER ( SUPPORTS 2 USB 2.0 PORTS) , 1 X USB 3.2 GEN1 HEADER ( SUPPORTS 2 USB 3.2 GEN1 PORTS) 1 X FRONT PANEL TYPE C USB 3.2 GEN 2 HEADER (10GB/S) |
| BACK PANEL CONNECTORS | 2 X ANTENNA PORTS , 1 X HDMI PORT , 1 X DISPLAY PORT 1.4 , 1 X USB 3.2 GEN2 TYPE-A PORT ( 10GB/S) , 1 X USB 3.2 GEN2 TYPE-C PORT (10GB/S) , 4 X USB 3.2 GEN1 PORTS , 2 X USB 2.0 PORTS , 1 X RJ-45 LAN PORT , HD AUDIO JACKS: LINE IN/ FRONT SPEAKER / MICROPHONE |
| SIZE | |
| UNIQUE FACTORS | SUPERB PRODUCTIVITY , PCIe GEN5 (GRAPHICS) , DUAL CHANNEL DR5 , ROCK - SOLID DURALIBILITY , 10+1+1 POWER PHASE , 50A DR.MOS FOR VCORE+GT , PRE-INSTALLED I/O SHIELD , ULTRAFAST CONNECTIVITY , 2.5G LAN , 802.11ax WI-FI 6E MODULE , EZ UPDATE , ASROCK AUTO DRIVE INSTALLER , EZ TROUBLESHOOTER. |
