ASUS B760 FG WIFI STRIX
The ASUS ROG Strix B760-F Gaming WiFi is an ATX motherboard supporting 12th-14th Gen Intel processors, DDR5 memory, PCIe 5.0, triple M.2 slots, WiFi 6E, and 2.5Gb LAN—offering high-speed connectivity, robust power delivery, and gaming-focused feature
Features
The ASUS ROG Strix B760-F Gaming WiFi is a high-performance ATX motherboard designed for gamers, creators, and power users who want next-gen connectivity and rock-solid stability. Built for 14th, 13th and 12th Gen Intel Core processors, it supports the LGA 1700 socket and fully harnesses DDR5 memory for ultra-fast data transfer and improved system responsiveness.
Key Features and Specifications:
-
CPU Support: Compatible with 14th, 13th & 12th Gen Intel Core, Pentium Gold, and Celeron processors (LGA 1700).
-
Chipset: Intel B760 chipset optimized for gaming and high-speed I/O.
-
Memory:
-
Supports DDR5 memory up to 7800+ MHz (OC)
-
4 DIMM slots, dual-channel architecture, and Intel XMP 3.0 profiles for effortless overclocking.
-
-
Expansion Slots:
-
PCIe 5.0 x16 slot for latest-generation graphics cards
-
Additional PCIe 4.0 and 3.0 slots for expansion cards
-
-
Storage Options:
-
Triple PCIe 4.0 M.2 slots with heatsinks for ultra-fast NVMe SSDs
-
6x SATA 6Gb/s ports for traditional storage drives
-
-
Networking:
-
WiFi 6E for low-latency, high-speed wireless connectivity
-
Intel 2.5Gb Ethernet for stable wired connections
-
-
USB Connectivity:
-
Multiple USB 3.2 Gen 2x2, Gen 2, and Gen 1 ports, including USB Type-C® for fast peripheral support
-
-
Audio:
-
ROG SupremeFX 7.1 audio codec with high-fidelity sound for immersive gaming and content creation
-
-
Power Design:
-
16+1 power stages with high-quality alloy chokes and capacitors for stable CPU performance under load
-
-
Cooling Solutions:
-
Comprehensive heatsinks on VRM, chipset, and M.2 slots
-
AI cooling optimizations and multiple fan headers for custom thermal management
-
-
BIOS & Software Features:
-
UEFI BIOS with AI Overclocking and user-friendly interface
-
ASUS Armoury Crate for centralized control of RGB lighting, fan speeds, and system tuning
-
-
Aesthetic Design:
-
Sleek ROG Strix styling with RGB Aura Sync lighting
-
Reinforced PCIe slots and durable PCB for long-lasting reliability
-
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13THGEN PROCESSORS , INTEL CORE 12TH GEN PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | 4 X DIMM, MAX. 192GB, DDR5 7800(OC) /7000(OC) /6800(OC) /6600(OC) / 6400(OC) /6200(OC) /6000(OC) / 5800(OC) /5600 /5400 /5200 /5000 /4800 MHzNON-ECC, UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X INTEL 2.5GB ETHERNET , ASUS LANGUARD , WI-FI 6E, 2 X WI-FI 6E ( 802.11 a/b/g/n/ac/ax) , supports 2.4/5/6GHZ FREQUNECY BAND , BLUETOOH V5.3 , WIFI 6E 6GHz REGULATORY MAY VARY BETWEEN COUNTRIES |
| AUDIO | ROG SUPREMEFX 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC ALC4080 |
| EXPANSION SLOTS | 1 X PCIe 5.0x16 SLOT ( SUPPORTS X16 MODE) , 1 X PCIe 3.0 x16 SLOT (SUPPORTS X4 MODE ) , 2 X PCIe 3.0 X1 SLOTS |
| STORAGE INTERFACES | M.2_1 SLOT ( KEY M ) , TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4 MODE) , M.2_2 SLOT (KEY M,)TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4) , M.2_3 SLOT (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4- PIN CPU FAN HEADER, 1 X 4 PIN CPU OPT FAN HEADER , 1 X 4 PIN AIO PUMP HEADER , 4 X PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 1 X 4 PIN +12V POWER CONNECTOR , 3 X M.2 SLOTS (KEY M ) , 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 2 CONNECTOR (SUPPORTS USB TYPE C ) , 1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS , 3 X ADDRESSSABLE GEN 2 HEADERS , 1 X AURA RGB HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP) , 1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION , 1 X THERMAL SENSOR HEADER , 1 X THUNDERBOLT (USB4) HEADER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C) , 1 X USB 3.2 GEN 2 PORT (1 X TYPE A ) , 6 X USB 3.2 GEN 1 PORTS (6 X TYPE A ) , 1 X DISPLAY PORT ,1 X HDMI PORT , 1 X WIFI MODULE , 1 X INTEL 2.5GB ETHERNET PORT , 5 X AUDIO JACKS , 1 X OPTICAL S/PDIF OUT PORT , 1 X BIOS FLASH BACK BUTTON , 1 X CLEAR CMOS BUTTON |
| SIZE | FULL ATX |
| UNIQUE FACTORS | EXTREME ENGINE DIGI+ , 5K BLACK METALLIC CAPACITORS , ASUS Q DESIGN , M.2 Q- LATCH , PCIe SLOT Q RELEASE , Q-DIMM, Q-LED (CPU[RED], DRAM[YELLOW], VGA [WHITE], BOOT DEVICE [YELLOW GREEN]) , Q-SLOT , ASUS THERMAL SOLUTION , M.2 HEATSINK , VRM HEATSINK , BIOS FLASHBACK BUTTON , BIOS FLASHBACK LED , CLEAR CMOS BUTTON , CPU SOCKET LEVER PROTECTOR , PROCOOL, PRE-MOUTNED I/O SHIELD , SAFESLOT , SAFEDIMM, AURA RGB HEADER , ADDRESSABLE GEN 2 HEADERS |
