ASUS B760M A WIFI PRIME
The ASUS Prime B760M-A WiFi is a micro-ATX motherboard supporting 12-14th Gen Intel processors, DDR5 memory, PCIe 4.0, dual M.2 slots, WiFi 6, and 2.5Gb LAN—delivering efficient performance, reliable power delivery, and versatile connectivity.
Features
The ASUS PRIME B760M-A WiFi is a reliable, feature-rich micro-ATX motherboard designed for productivity, mainstream builds, and home or office PCs. It’s built to fully support 12th to 14th Gen Intel Core processors with the LGA 1700 socket, delivering a solid balance of performance, connectivity, and value. Part of the ASUS PRIME series, it focuses on stability, efficiency, and ease of use with robust power delivery, comprehensive cooling, and next-gen features.
Key Features and Specifications
Processor Support
-
Compatible with 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors (LGA 1700)
-
Optimized for Intel hybrid architecture for enhanced multitasking
Chipset
-
Intel B760 chipset, ensuring up-to-date I/O options and support for high-speed storage and memory
Memory
-
4x DIMM slots supporting DDR5 memory up to 7000+ MHz (OC)
-
Dual-channel memory architecture with Intel XMP 3.0 profiles for quick performance tuning
-
Maximum memory capacity up to 128GB
Expansion Slots
-
PCIe 4.0 x16 slot (reinforced) for modern graphics cards
-
Additional PCIe 3.0 slots for expansion cards
Storage
-
Dual PCIe 4.0 M.2 slots with dedicated heatsinks for high-speed NVMe SSDs
-
4x SATA 6Gb/s ports for HDDs and SATA SSDs
-
Supports RAID 0/1/5/10 configurations for performance and redundancy
Networking
-
WiFi 6 (802.11ax) for fast, low-latency wireless networking
-
Intel 2.5Gb Ethernet for stable wired connections
USB Connectivity
-
Rear I/O includes:
-
USB 3.2 Gen 2 Type-C®
-
USB 3.2 Gen 1 and Gen 2 Type-A
-
USB 2.0 ports for peripherals
-
-
Front panel headers include USB Type-C and Type-A options
Audio
-
Realtek high-definition audio codec delivering clear, distortion-free sound for everyday use
Power Delivery
-
8+1 DrMOS power stages with durable alloy chokes and capacitors for stable CPU performance
-
Optimized VRM heatsinks to maintain power efficiency under load
Cooling Solutions
-
Comprehensive heatsinks on VRM and chipset
-
Multiple fan headers with PWM/DC control
-
ASUS Fan Xpert 2+ software for intelligent cooling control
BIOS & Software
-
UEFI BIOS with EZ Mode and Advanced Mode for both beginners and enthusiasts
-
ASUS Armoury Crate for driver updates, system monitoring, and Aura Sync RGB control
Design & Aesthetics
-
Clean, silver-and-white PCB design for versatile system themes
-
Addressable RGB headers compatible with ASUS Aura Sync lighting ecosystem
-
Reinforced PCIe slots for long-term durability
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13TH GEN PROCESSORS , INTEL CORE 12TH, GEN PENTIUM GOLD AND CELELRON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | 4 X DIMM SLOTS, MAX. 192GB , DDR5 7200+(OC) /7000(OC) /6800(OC) /6600(OC )/6400(OC) /6200(OC) /6000(OC) /5800(OC) /5600 /5400 /5200 /5000 /4800 MHzNON-ECC , UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X REALTEK 2.5GB ETHERNET , WIFI 6 , 2X2 WIFI 6 (802.11 a/b/g/n/ac/ax), supports 2.4/5GHz FREQUENCY BAND , BLUETOOTH V5.2 |
| AUDIO | REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 4.0 X16 SLOT , 1 X PCIe 4.0 X16 SLOT (SUPPORTS X4 MODE ) , 1 X PCIe 4.0 X16 SLOT (SUPPORT X1 MODE ) |
| STORAGE INTERFACES | M.2_1 SLOT (KEY M ), TYPE 2242/2260/2280(SUPPORTS PCIe 4.0 X4 MODE ) , M.2_2 SLOT (KEY M ), TYPE 2242/2260/2280 SUPPORTS PCIe 4.0 X4 MODE) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN CPU OPT FAN HEADER , 2 X 4 PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 2 X M.2 SLOTS (KEY M ) , 4 X SATA 6GB/S PORTS , 2 X USB 3.2 GEN 1 HEADERS SUPPORT 4 ADDITIONAL USB 3.2 GEN 1 PORTS , 1 X USB 3.2 GEN 1 CONNECTOR ( SUPPORTS USB TYPE C ) , 2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS , 1 X USB 2.0 HEADER SUPPORTS 1 ADDITONAL USB 2.0 PORT , 3 X ADDRESSABLE GEN 2 HEADERS , 1 X AURA RGB HEADER , 1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP) , 1 X LPT HEADER , 1 X S/PDIF OUT HEADER 1 X SPI TPM HEADER (14-1PIN) , 1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION |
| BACK PANEL CONNECTORS | 2 X USB 3.2 GEN 2 PORTS (2 X TYPE-A), 4 X USB 2.0 PORTS (4 X TYPE ) , 1 X DISPLAY PORT , 2 X HDMI PORTS , 1 X WIFI MODULE 1 X REALTEK 2.5GB ETHERNET PORT , 3 X AUDIO JACKS , 1 X PS/2 KEYBOARD/MOUSE COMBO PORT |
| SIZE | MICRO-ATX |
| UNIQUE FACTORS | ASUS 5X PROTECTION III, DIGI+ VRM , LANGUARD , OVERVOLTAGE PROTECTION , SAFESLOT CORE+ , STAINLESS STEEL BACK I/O , Q-DIMM , Q LED CORE , Q SLOT , M.2 HEATSINK , VRM HEATSINK DESIGN , PROCOOL , AURA RGB HEADER ADDRESSABLE GEN 2 HEADERS |
