ASUS B760 PLUS PRIME
The ASUS Prime B760-PLUS ATX motherboard supports 12th to 14th Gen Intel® CPUs with DDR5 memory, PCIe 5.0, triple M.2 slots, Intel® 2.5Gb LAN, and comprehensive cooling—delivering stability, speed, and future-ready performance for productivity build.
Features
ASUS Prime B760-PLUS – PRIME
The ASUS Prime B760-PLUS is a robust ATX motherboard engineered for 14th to 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors, designed to deliver reliable performance, efficient power delivery, and flexible connectivity for productivity and everyday computing. Built on the Intel® B760 chipset, it blends essential features with ASUS’ renowned durability and tuning capabilities.
Key Features and Specifications
1. Processor & Chipset Support
-
Compatible with Intel® LGA1700 socket
-
Supports 12th to 14th Gen Intel® Core™, Pentium® Gold, and Celeron® CPUs
-
Optimized power design for enhanced performance under load
2. Memory
-
Supports DDR5 memory up to 128GB
-
Dual-channel architecture for improved bandwidth
-
Memory overclocking support to boost performance
3. Expansion & Storage
-
1× PCIe 5.0 x16 slot for next-gen graphics cards
-
1× PCIe 3.0 x16 (max x4 mode) and 2× PCIe 3.0 x1 slots for additional devices
-
3× M.2 slots (PCIe 4.0) for high-speed NVMe SSDs
-
4× SATA 6Gb/s ports for HDDs and SSDs
4. Networking & Connectivity
-
Intel® 2.5Gb Ethernet for ultra-fast, reliable wired networking
-
USB 3.2 Gen 2 Type-C and USB 3.2 Gen 1 ports for modern peripherals
-
Multiple USB 2.0 ports for legacy devices
5. Graphics Support
-
Integrated GPU support via CPU with HDMI®, DisplayPort™, and D-Sub outputs
-
Supports 4K resolution output for enhanced clarity
6. Audio
-
Realtek high-definition 7.1-channel audio
-
Premium audio capacitors for clear, immersive sound
7. Cooling & Design
-
Comprehensive cooling solution with large VRM heatsinks and hybrid fan headers
-
ASUS Fan Xpert for advanced fan control and optimized thermal performance
-
Durable PCB with reinforced PCIe slots for improved reliability
8. BIOS & Software Features
-
ASUS UEFI BIOS with user-friendly interface for easy configuration
-
AI Overclocking and AI Cooling features to simplify tuning
-
Armoury Crate software for driver updates, system monitoring, and customization
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13TH GEN PROCESSORS , INTEL CORE 12TH GEN , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | 4 X DIMM, MAX. 192GB , DDR5 7200+(OC) /7000(OC) / 6800(OC) /6600(OC) / 6400(OC) /6200(OC) /6000(OC) / 5800(OC) /5600 /5400 /5200 /5000 /4800 NON-ECC, UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X REALTEK 2.5GB ETHERNET , VERTICAL M.2 SLOT ONLY (KEY E, CNVi & PCIe) , WIFI MODULE IS SOLD SEPARATELY |
| AUDIO | REALTEK 7.1 SURROUND SOUND HIGH DEFINITON AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 5.0 X16 SLOT , 1 X PCIe 4.0 X16 SLOT ( SUPPORTS X4 MODE ) , 2 X PCIe 3.0 X1 SLOTS |
| STORAGE INTERFACES | M.2_1 SLOT (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4 MODE ) , M.2_2 SLOT ( KEY M ), TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4 MODE) , M.2_3 SLOT (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X2 MODE ) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN AIO PUMP HEADER , 3 X 4 PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 3 X M.2 SLOTS (KEY M) , 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 1 CONNECTOR (SUPPORTS USB TYPE C ) , 1 X USB 3.2 GEN 1 HEADER SUPPORTS 2 ADDITIONAL USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT 4 VADDITIONAL USB 2.0 PORTS , 3 X ADDRESSABLE GEN 2 HEADERS , 1 X AURA RGB HEADER , 1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP ) , 1 X SPI TPM HEADER (14-1PIN) , 1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUCNTION , 1 X THUNDERBOLT (USB4 ) HEADER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT ( 1 X USB TYPE-C) , 2 X USB 3.2 GEN 2 PORTS ( 2 X TYPE A ) , 1 X USB 3.2 GEN 1 PORT (1 X TYPE A ) , 2 X USB 2.0 PORTS (2 X TYPE A ) , 1 X DISPLAY PORT , 1 X VGA PORT , 1 X HDMI PORT , 1 X VERTICAL M.2 SLOT (KEY E ) , 1 X REALTEK 2.5GB ETHERNET PORT , 3 X AUDIO JACKS |
| SIZE | FULL ATX |
| UNIQUE FACTORS | ASUS 5X PROTECTION III , DIGI+ VRM , LAN GUARD , OVERVOLTAGE PROTECTION , SAFESLOT CORE+ , STAINLESS STEEL BACK I/O , Q- DIMM , Q-LED CORE , Q SLOT , M.2 HEATSINK , VRM HEATSINK DESIGN , PROCOOL , AURA RGB HEADER , ADDRESSABLE GEN 2 HEADERS |
