ASUS H510 ME
The ASUS H510M-E is a micro-ATX motherboard supporting 10th/11th Gen Intel® processors, DDR4 memory, PCIe 4.0, dual M.2 slots, and comprehensive connectivity—delivering reliable performance and essential features for compact, budget-friendly PC build
Features
The ASUS H510M-E is a compact micro-ATX motherboard designed to deliver dependable performance and essential features for everyday computing, powered by 10th and 11th Gen Intel® Core™, Pentium® Gold, and Celeron® processors. Built with ASUS’ renowned engineering, it balances stability, compatibility, and affordability for home or office PC builds.
Key Features and Specifications:
Processor Support
-
Compatible with 10th and 11th Gen Intel® Core™, Pentium® Gold, and Celeron® CPUs on the LGA1200 socket.
-
Optimized power delivery to ensure consistent and efficient performance.
Memory
-
Supports DDR4 memory up to 3200 MHz (OC) for Intel® 11th Gen and up to 2933 MHz for Intel® 10th Gen.
-
Dual DIMM slots with a maximum capacity of 64GB, providing flexibility for productivity or light gaming.
Expansion and Graphics
-
1 × PCIe 4.0 x16 slot (for 11th Gen CPUs) and 1 × PCIe 3.0 x1 slot for add-in cards.
-
Integrated Intel® UHD Graphics support with HDMI™ 1.4 and D-Sub outputs, supporting multiple display configurations.
Storage
-
1 × M.2 slot (PCIe 3.0 x4/SATA) for fast NVMe or SATA SSDs.
-
4 × SATA 6Gb/s ports for additional storage devices.
Networking and Audio
-
Intel® Gigabit LAN ensures stable and high-speed wired networking.
-
Realtek 8-channel HD Audio provides clear, immersive sound for work or entertainment.
Connectivity and I/O
-
Rear panel includes USB 3.2 Gen 1 Type-A, USB 2.0 ports, HDMI, D-Sub, and audio jacks.
-
Front-panel USB headers for additional ports on compatible PC cases.
ASUS Exclusive Features
-
5X Protection III: Hardware safeguards with SafeSlot Core, overvoltage protection, and reinforced power delivery.
-
UEFI BIOS with EZ Mode for easy system tuning and configuration.
-
Fan Xpert for precise fan control, ensuring optimal cooling and noise reduction.
Specifications
| CPU | INTEL SOCKET LGA 1200 FOR 11TH GEN INTEL CORE PROCESSORS & 10TH GEN INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | H510 |
| MEMORY | 2 X DIMM, MAX. 64GB, DDR4 3200(OC) /2933 /2800 /2666 /2400 /2133 MHz NON-ECC, UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X INTEL I219-V 1GB ETHERNET |
| AUDIO | REALTEK ALC897/887 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 4.0/3.0 X16 SLOT , INTEL 11TH GEN PROCESSORS SUPPORT PCIe 4.0 X16 , INTEL 10TH GEN PROCESSORS SUPPORT PCIe 3.0 X16 , 2 X PCIe 3.0 X1 SLOTS |
| STORAGE INTERFACES | M.2 SLOT (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 3.0 X4 & SATA MODES ) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN CHASSIS FAN HEADER , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8-PIN +12V POWER CONNECTOR , 1 X M.2 SLOT (KEY M ) , 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 1 HEADER SUPPORTS ADDITIONAL 2 USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 4 USB 2.0 PORTS , 1 X RGB HEADER , 1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP) 1 X S/PDIF OUT HEADER , 1 X SPEAKER HEADER , 1 X SPI TPM HEADER (14-1PIN), 1 X 10 -1 PIN SYSTEM PANEL HEADER |
| BACK PANEL CONNECTORS | 2 X USB 3.2 GEN 1 PORTS (2 X TYPE A ) , 2 X USB 2.0 PORTS (2 X TYPE A ) , 1 X DISPLAY PORT , 1 X D-SUB PORT , 1 X HDMI PORT , 1 X INTEL I219-V 1GB ETHERNET PORT , 3 X AUDIO JACKS , 1 X PS/2 KEYBOARD (PURPLE) PORT , 1 X PS/2 MOUSE (GREEN PORT) |
| SIZE | |
| UNIQUE FACTORS | ASUS 5X PROTECTION III , DIGI+ VRM LANGUARD , OVERVOLTAGE PROTECTION , SAFESLOT CORE , STAINLESS-STEEL BACK I/O , Q-DIMM, Q-SLOT , ALIMINUM HEATSINK DESIGN , RGB HEADER |
