ASUS Z690-A DDR5 PRIME
The ASUS Prime Z690-A DDR5 motherboard supports 12th to 14th Gen Intel® Core™ processors with PCIe 5.0, ultra-fast DDR5 memory, 4x M.2 slots, 2.5Gb LAN, robust 16+1 power stages, advanced cooling, and customizable Aura Sync RGB.
Features
The ASUS Prime Z690-A DDR5 motherboard blends cutting-edge performance, robust power delivery, and premium features tailored for both enthusiasts and professional users. Based on Intel’s flagship Z690 chipset, it supports 12th to 14th Gen Intel® Core™ processors on the LGA 1700 socket, ensuring next-generation performance for gaming, content creation, and productivity.
Key Features and Specifications:
-
Processor Support: Designed for 12th to 14th Gen Intel® Core™, Pentium® Gold, and Celeron® processors, delivering high performance with PCIe 5.0 and DDR5 support.
-
Memory: Supports up to 128GB DDR5 memory at speeds up to 6000+ MHz (OC), providing faster data throughput and improved multitasking.
-
Power Design: A robust 16+1 DrMOS power stage VRM configuration with premium capacitors and ProCool connectors ensures efficient, stable power delivery even under extreme overclocking.
-
Expansion: PCIe 5.0 x16 slot with SafeSlot reinforcement for next-gen GPUs, along with multiple PCIe 4.0 slots for additional add-in cards.
-
Storage:
-
4x M.2 slots (PCIe 4.0) with heatsinks for ultra-fast NVMe SSDs.
-
6x SATA 6Gb/s ports for additional storage devices.
-
-
Networking: Intel® 2.5Gb Ethernet for high-bandwidth, low-latency networking, perfect for online gaming and large data transfers.
-
USB Connectivity: Multiple high-speed USB ports including USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2, and USB 2.0 for extensive device compatibility.
-
Cooling Solutions: Comprehensive cooling with large VRM heatsinks, hybrid fan headers, AIO pump headers, and M.2 heatsinks to maintain peak performance.
-
Audio: High-fidelity Realtek S1220A 7.1-channel HD audio codec with DTS support for crystal-clear sound and immersive experiences.
-
Aesthetics: Striking silver-and-black design with integrated ARGB lighting and ASUS Aura Sync support for full RGB customization.
-
AI Features:
-
AI Overclocking – automated performance tuning for optimal CPU speed.
-
AI Cooling – smart fan speed adjustments to maintain efficiency and low noise.
-
AI Networking (GameFirst VI) – prioritizes bandwidth for critical applications.
-
-
ASUS SafeSlot & TUF Protection: Reinforced PCIe slots and comprehensive protection features (overvoltage, ESD guards, stainless-steel back I/O) for durability.
Specifications
| CPU | INTEL 12TH, 13TH AND 14TH GEN CPU |
|---|---|
| CHIPSET | Z690 |
| MEMORY | 192GB , 4 X DIMM , MAX. 128GB , DDR5 6000(OC) /5800(OC) /5600(OC) /5400(OC) /5200(OC) /5000(OC) /4800 NON-ECC, UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X INTEL 2.5GB ETHERNET , ASUS LANGUARD |
| AUDIO | REALTEK S1220A 7.1 SURROUND SOUND HIGH DEFINITON AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 5.0/4.0/3.0 X16 SLOTS , 1 X PCIe 3.0 X16 SLOT (SUPPORTS X4 MODE ) 1 X PCIe 3.0 X4 SLOT , 2 X PCIe 3.0 X1 SLOTS |
| STORAGE INTERFACES | SUPPORTS 4 X M.2 SLOTS AND 4 X SATA 6GB/S PORTS , M.2_1 SLOT (KET M), TYPE 2242/2260/2280/22110 , INTEL 12TH GEN PROCESSORS SUPPORT PCIe 4.0 X4 MODE , M.2_2 SLOT (KEY M ) , TYPE 2242/2260/2280(SUPPORTS PCIE 4.0 X4 MODE ) M.2_3 SLOT (KEY M) , TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 x4 MODE) , M.2_4 SLOT (KEY M) TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 x4 & SATA MODES ), 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADERS , 1 X 4 PIN CPU OPT FAN HEADERS , 1 X 4 PIN AIO PUMP HEADER , 4 X 4 PIN CHASSIS FAN HEADERS , 1 X W_PUMP+ HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 2 X 8 PIN +12V POWER CONNECTOR , 4 X M.2 SLOTS (KEY M ) , 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 2 CONNECTOR (SUPPORT USB TYPE C ) , 1 X USB 3.2 GEN 1 HEADER SUPPORT ADDITIONAL 2 USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADER SUPPORT ADDITIONAL 4 USB 2.0 PORTS , 3 X ADDRESSABLE GEN 2 HEADERS , 1 X AURA RGB HEADER , 1 X CLEAR CMOS BUTTON , 1 X COM PORT HEADER , 1 X CPU OVER VOLTAGE JUMPER , 1 X FRONT PANEL AUDIO HEADER (AAFP) , 1 X POWER BUTTON , 1 X SPI TPM HEADER (14-1 PIN ) , 1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION, 1 X THERMAL SENSOR HEADER , 1 X THUNDERBOLT HEADER , |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE C ) , 3 X USB 3.2 GEN 2 PORT ( 2 X TYPE A , 1 X TYPE C ) , 4 X USB 3.2 GEN 1 PORT (4 X TYPE A ) , 1 X DISPLAYPORT , 1 X HDMI PORT , 1 X INTEL 2.5 GB ETHERNET PORT , 5 X AUDIO JACKS , 1 X OPTICAL S/PDIF OUT PORT |
| SIZE | FULL ATX |
| UNIQUE FACTORS | DIGI + VRM (DIGITAL POWER DESIGN WITH DrMOS ) , ENHANCED DRAM OVERCURRENT PROTECTION , ESD GUARDS , LAN GUARDS , OVERVOLTAGE PROTECTION , SAFESLOT , STAINLESS STEEL BACK I/O , M.2 Q-LATCH , Q-CONNECTOR , Q-DIMM, Q-LED(CPU[RED], DRAM[YELLOW], VGA[WHITE], BOOT DEVICE[YELLOW GREEN] , Q-SLOT , M.2 HEATSINK BACKPLATE , M.2 HEATSINK, VRM HEATSINK DESIGN , BOX HEADERS , CLEAR CMOS, BUTTON , CPU SOCKET LEVER PROTECTOR , PROCOOL , PRE-MOUNTED I/O SHIELD , AURA RGB HEADERS , ADRESSABLE GEN 2 HEADERS |
