ASUS Z690-P WIFI DDR4 PRIME
The ASUS Prime Z690-P WiFi DDR4 motherboard supports 12th to 14th Gen Intel processors, PCIe 5.0, triple M.2 slots, WiFi 6, 2.5Gb LAN, DDR4 memory up to 5333 MHz, and robust power delivery with AI optimization.
Features
The ASUS Prime Z690-P WiFi DDR4 is a feature-rich ATX motherboard designed to fully unleash the potential of 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors using the LGA1700 socket. Built with a 14+1 DrMOS power stage design and enhanced VRM cooling, it ensures stable power delivery for high-performance computing, content creation, and gaming.
This motherboard supports DDR4 memory up to 5333 MHz (OC) with dual-channel architecture, delivering exceptional speed and responsiveness for multitasking and heavy workloads. PCIe 5.0 x16 slot offers next-gen bandwidth for GPUs, while three PCIe 4.0 M.2 slots (with heatsinks) enable ultra-fast NVMe SSD storage, reducing latency and boosting system performance.
Networking and connectivity are equally robust with WiFi 6 (802.11ax) and Intel 2.5Gb Ethernet, providing high-speed, low-latency networking for both wired and wireless environments. Rear I/O includes USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2 Type-A, multiple USB 3.2 Gen 1/2.0 ports, HDMI, DisplayPort, and combined audio jacks powered by Realtek ALC897 for crystal-clear sound.
ASUS integrates AI Overclocking, AI Cooling, and AI Networking, simplifying system tuning while optimizing thermal performance and bandwidth usage automatically. The comprehensive cooling system features large VRM heatsinks, hybrid fan headers, and Fan Xpert 4 software control to maintain low temperatures under heavy load.
Other enhancements include Q-Latch for tool-free M.2 installation, Q-LED indicators for quick troubleshooting, and ProCool connectors for improved power efficiency. The sleek silver-accented PCB with Aura Sync RGB lighting support lets users customize aesthetics to match any build theme.
Key Specifications:
-
Socket: Intel LGA1700
-
Chipset: Intel Z690
-
Memory: 4× DDR4 DIMM, up to 128GB, up to 5333 MHz (OC)
-
Expansion: PCIe 5.0 x16, PCIe 3.0/4.0 x16 (x4), PCIe 3.0 x1
-
Storage: 3× PCIe 4.0 M.2 slots, 4× SATA 6Gb/s ports
-
Networking: Intel WiFi 6, Intel 2.5Gb Ethernet
-
USB: USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2 Type-A, USB 3.2 Gen 1, USB 2.0
-
Audio: Realtek ALC897 7.1-Channel HD Audio
-
Form Factor: ATX
The ASUS Prime Z690-P WiFi DDR4 is ideal for enthusiasts and professionals seeking cutting-edge performance, comprehensive connectivity, and dependable stability in a future-ready motherboard platform.
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13TH GEN PROCESSORS , INTEL CORE 12TH GEN , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | Z690 |
| MEMORY | 4 X DIMM , MAX. 128GB, DDR4 5333(OC) /5133(OC) /5000(OC) /4800(OC) /4600(OC) /4400(OC) /4266(OC) /4133(OC) /4000(OC) /3866(OC) /3733(OC) /3600(OC) /3466(OC) /3400(OC) /3333(OC) /3200 /3000 /2933 /2800 /2666 /2400 /2133 NON-ECC UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X REALTEK 2.5GB ETHERNET , WIFI 6 , 2X2 WIFI 6 (802.11 a/b/g/n/ac/ax) SUPPORTS 2.4/5GHz FREQUENCY BAND , BLUETOOTH V5.2 |
| AUDIO | REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 5.0/4.0/3.0 X16 SLOT , 1 X PCIe 4.0/3.0/ X16 SLOT (SUPPORTS X4 MODE ) , 2 X PCIe 3.0 X16 SLOTS (SUPPORT X4 MODE) , 1 X PCIe 3.0 X1 SLOT |
| STORAGE INTERFACES | M.2_1 SLOT (KEY M ) , TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4 MODE ) , M.2_2 SLOT (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4 MODE ) , M.2_3 SLOT (KEY M ), TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4 & SATA MODES ) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN CPU OPT FAN HEADER , 1 X 4 PIN AIO PUMP HEADER , 3 X 4 PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 1 X 4 PIN +12V POWER CONNECTOR , 3 X M.2 SLOTS (KEY M ), 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 1 CONNECTOR (SUPPORTS USB TYPE-C) , 2 X USB 3.2 GEN 1 HEADERS SUPPORT ADDITIONAL 4 USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 4 USB 2.0 PORTS , 3 X ADDRESSABLE GEN 2HEADERS , 1 X AURA RGB HEADER , 1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C) , 1 X USB 3.2 GEN 2 PORT (1 X TYPE-A ) , 2 X USB 3.2 GEN 1 PORTS (2 X TYPE -A) , 2 X USB 2.0 PORTS ( 2 X TYPE-A) , 1 X DISPLAY PORT , 1 X HDMI PORT , 1 X WIFI MODULE , 1 X REALTEK 2.5GB ETHERNET PORT , 5 X AUDIO JACKS , 1 X OPTICAL S/PDIF OUT PORT , 1 X PS/2 KEYBOARD/MOUSE COMBO PORT |
| SIZE | FULL ATX |
| UNIQUE FACTORS | DIGI+ VRM (DIGITAL POWER DESIGN WITH DrMOS) , LANGUARD, OVERVOLTAGE PROTECTION , SAFESLOT , STAINLESS STEEL BACK I/O , Q-DIMM , Q-SLOT , FLEXIBLE M.2 HEATSINK , VRM HEATSINK DESIGN , PROCOOL , AURA RGB HEADER , ADDRESSABLE GEN 2 HEADERS |
