ASUS Z790 P DDR4 PRIME
ASUS PRIME Z790-P DDR4 delivers powerful performance with Intel 12th to 14th Gen CPU support, robust power delivery, PCIe 5.0, DDR4 memory, triple M.2 slots, USB 3.2 Gen 2, AI cooling, and comprehensive connectivity for stable high-end computing.
Features
The ASUS Prime Z790-P DDR4 motherboard is engineered for 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors on the LGA1700 socket, delivering outstanding performance, stability, and expandability for advanced gaming, content creation, and productivity builds. With the Intel Z790 chipset, it combines cutting-edge bandwidth, power efficiency, and overclocking capabilities to meet the demands of high-end users.
Performance and Power Design
Equipped with a 14+1 DrMOS power stage VRM and ProCool solid-pin power connectors, the Prime Z790-P DDR4 ensures consistent, reliable power delivery even under heavy workloads. High-quality capacitors and alloy chokes enhance durability and thermal performance, providing headroom for CPU overclocking.
Memory and Storage
The motherboard supports DDR4 memory up to 5333 MHz (OC) with dual-channel architecture and up to 128GB capacity, ensuring fast responsiveness and low latency for demanding applications. Storage flexibility is excellent, featuring three PCIe 4.0 M.2 slots with heatsinks to maintain optimal SSD performance, alongside four SATA 6Gb/s ports for additional drives.
Expansion and Graphics Support
The PCIe 5.0 x16 slot delivers next-generation bandwidth for modern GPUs, making it ideal for high-resolution gaming or professional rendering. Additional PCIe 4.0/3.0 slots offer versatility for expansion cards.
Connectivity and Networking
Stay connected with Intel 2.5Gb Ethernet, offering low-latency, high-speed wired networking for online gaming, streaming, and data transfer. Rear I/O includes USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2 Type-A, multiple USB 3.2 Gen 1 and USB 2.0 ports, plus DisplayPort and HDMI outputs for integrated graphics.
Audio
The Realtek 7.1-channel HD audio codec delivers clear, immersive sound for gaming and media consumption.
Advanced Cooling Solutions
The Prime Z790-P DDR4 incorporates large VRM heatsinks, hybrid fan headers, and Fan Xpert 4 software to automatically manage airflow and keep critical components cool under heavy load.
AI and Ease of Use Features
ASUS integrates AI Overclocking, AI Cooling, and AI Networking to optimize performance and efficiency with minimal manual tuning. Installation is simplified with M.2 Q-Latch for tool-free SSD installation, Q-LED troubleshooting indicators, and Pre-mounted I/O shield for streamlined building.
Aesthetics and Customization
Featuring Aura Sync RGB lighting support, users can synchronize lighting effects across compatible components and peripherals to create a personalized build theme.
Key Specifications:
-
Socket: Intel LGA1700
-
Chipset: Intel Z790
-
Memory: 4× DDR4 DIMM, up to 128GB, up to 5333 MHz (OC)
-
Expansion: PCIe 5.0 x16, PCIe 4.0/3.0 slots
-
Storage: 3× PCIe 4.0 M.2 slots with heatsinks, 4× SATA 6Gb/s ports
-
Networking: Intel 2.5Gb Ethernet
-
USB Ports: USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2 Type-A, USB 3.2 Gen 1, USB 2.0
-
Audio: Realtek 7.1-Channel HD Audio
-
Form Factor: ATX
The ASUS Prime Z790-P DDR4 is a future-ready motherboard that blends robust performance, broad connectivity, and intuitive features—ideal for enthusiasts, professionals, and power users who demand reliability and flexibility from their PC platform.
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13TH GEN PROCESSORS , INTEL CORE 12TH GEN , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | Z690 |
| MEMORY | 4 X DIMM , MAX. 128GB, DDR4 5333(OC) /5133(OC) /5066(OC) /5000(OC) /4800(OC) /4700(OC) /4600(OC) /4500(OC) /4400(OC) /4266(OC) /4133(OC) /4000(OC) /3866(OC) /3733(OC) /3600(OC) /3466(OC) /3400(OC) /3333(OC) /3200 /3000 /2933 /2800 /2666 /2400 /2133 NON-ECC UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X REALTEK 2.5GB ETHERNET , VERTICAL M.2 SLOT ONLY (KEY E CNVi & PCIe) WI-FI MODULE IS SOLD SEPARATELY |
| AUDIO | REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 5.0 X16 SLOTS , 3 X PCIe 4.0 X16 SLOTS (SUPPORT X4 MODE ) , 1 X PCIe 3.0 X1 SLOT |
| STORAGE INTERFACES | M.2_1 SLOT (KEY M ) , TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4 MODE ) , M.2_2 SLOT TYPE (KEY M ), TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4 MODE ) , M.2_3 SLOT (KEY M ), TYPE 2242/2260/2280/22110 (SUPPORTS PCIe 4.0 X4 & SATA MODES ) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN CPU OPT FAN HEADER , 1 X 4 PIN AIO PUMP HEADER , 3 X 4 PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 1 X 4 PIN +12V POWER CONNECTOR , 3 X M.2 SLOTS (KEY M ), 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 1 CONNECTOR (SUPPORTS USB TYPE-C) , 2 X USB 3.2 GEN 1 HEADERS SUPPORT ADDITIONAL 4 USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT ADDITIONAL 4 USB 2.0 PORTS , 3 X ADDRESSABLE GEN 2HEADERS , 1 X AURA RGB HEADER , 1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP) , 1 X S/PDIF OUT HEADER , 1 X SPI TPM HEADER (14-1PIN) , 1 X 20-5 SYSTEM PANEL HEADER , 1 X THUNDERBOLT (USB4) HEADER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C) , 1 X USB 3.2 GEN 2 PORT (1 X TYPE-A ) , 2 X USB 3.2 GEN 1 PORTS (2 X TYPE -A) , 4 X USB 2.0 PORTS (4 X TYPE A ) , 1 X DISPLAYPORT , 1 X HDMI PORT , 1 X VERTICAL M.2 SLOT (KEY E) , 1 X REALTEK 2.5GB ETHERNET PORT , 3 X AUDIO JACKS , 1 X PS/2 KEYBOARD/MOUSE COMBO PORT |
| SIZE | FULL ATX |
| UNIQUE FACTORS | DIGI+ VRM (DIGITAL POWER DESIGN WITH DrMOS) , LANGUARD, OVERVOLTAGE PROTECTION , SAFESLOT CORE+, STAINLESS STEEL BACK I/O , Q-DIMM , Q-SLOT , Q-LED CORE , FLEXIBLE M.2 HEATSINK , VRM HEATSINK DESIGN , PROCOOL , AURA RGB HEADER , ADDRESSABLE GEN 2 HEADERS |
