ASUS Z790M PLUS DDR4 PRIME
The ASUS PRIME Z790M-PLUS DDR4 motherboard offers powerful performance with 12th to 14th Gen Intel CPU support, PCIe 5.0, DDR4 memory, advanced cooling, and versatile connectivity, ideal for compact, high-performance productivity and gaming builds.
Features
The ASUS PRIME Z790M-PLUS DDR4 motherboard is engineered to unlock the full potential of Intel’s 12th to 14th Gen Core processors, delivering stable performance, versatile connectivity, and reliable cooling for both productivity and gaming in a micro-ATX form factor.
Key Features and Specifications
1. CPU Support
-
Compatible with 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors
-
Intel LGA 1700 socket with robust 10+1 DrMOS power stages for stable power delivery
2. Memory
-
Supports DDR4 memory up to 5333 MHz (OC)
-
Dual-channel architecture with 4 DIMM slots, up to 128GB total capacity
3. Expansion and Storage
-
PCIe 5.0 x16 slot for next-gen graphics cards with improved bandwidth
-
Multiple PCIe 4.0 M.2 slots with NVMe SSD RAID support for ultra-fast storage speeds
-
4 × SATA 6Gb/s ports for additional storage options
4. Connectivity
-
USB 3.2 Gen 2 Type-C port for high-speed data transfer
-
Multiple USB 3.2 Gen 1 and USB 2.0 ports for peripherals
-
Realtek 2.5Gb Ethernet for ultra-fast wired networking
5. Audio
-
High-quality Realtek ALC897 audio codec delivering immersive sound
-
Premium audio capacitors and PCB shielding for cleaner output
6. Cooling and Reliability
-
Comprehensive cooling solutions: large VRM heatsinks, hybrid fan headers, and Fan Xpert 4 software control
-
ASUS DIGI+ VRM ensures precise voltage regulation and durability
-
SafeSlot Core+ reinforced PCIe slots for added GPU protection
7. Additional Features
-
AI Overclocking and AI Cooling II for easy, intelligent system tuning
-
ASUS Aura Sync RGB lighting with onboard headers for synchronized effects
-
Q-LED indicators and BIOS FlashBack for simplified troubleshooting and updates
Conclusion
The ASUS PRIME Z790M-PLUS DDR4 is an excellent choice for users seeking a compact, feature-rich motherboard that balances performance, connectivity, and value, making it perfect for high-performance PCs, gaming builds, and creative workstations.
Specifications
| CPU | INTEL SOCKET LGA1700 FOR INTEL CORE 14TH & 13TH GEN PROCESSORS , INTEL CORE 12TH GEN , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | Z790 |
| MEMORY | 4 X DIMM , MAX. 128GB, DDR4 5333(OC) /5133(OC) /5066(OC) /5000(OC) /4800(OC) /4700(OC) /4600(OC) /4500(OC) /4400(OC) /4266(OC) /4133(OC) /4000(OC) /3866(OC) /3733(OC) /3600(OC) /3466(OC) /3400(OC) /3333(OC) /3200 /3000 /2933 /2800 /2666 /2400 /2133 NON-ECC , UN-BUFFERED MEMORY |
| LAN + WIFI + BLUETOOTH | 1 X INTEL 1GB ETHERNET , ASUS LANGUARD , M.2 SLOT ONLY (KEY E, CNVi & PCIe) , WI-FI MODULE IS SOLD SEPARATELY |
| AUDIO | REALTEK 7.1 SURROUND SOUND HIGH DEFINITION AUDIO CODEC |
| EXPANSION SLOTS | 1 X PCIe 5.0 X16 SLOTS , 1 X PCIe 4.0 X1 SLOTS (SUPPORTS X4 MODE) , 2 X PCIe 4.0 X1 SLOTS |
| STORAGE INTERFACES | M.2_1 SLOT (KEY M) , TYPE 2242/2260/2280(SUPPORT PCIe 4.0 X4 MODE) , M.2_2 SLOT(KEY M ), TYPE 2260/2280/(SUPPORTS PCIe 4.0 X4 MODE) , M.2_3 SLOT (KEY M) , TYPE 2242/2260/2280 (SUPPORTS PCIe 4.0 X4 & SATA MODES ) , 4 X SATA 6GB/S PORTS |
| INTERNAL I/O CONNECTORS | 1 X 4 PIN CPU FAN HEADER , 1 X 4 PIN CPU OPT FAN HEADER , 1 X 4 PIN AIO PUMP HEADER , 3 X 4 PIN CHASSIS FAN HEADERS , 1 X 24 PIN MAIN POWER CONNECTOR , 1 X 8 PIN +12V POWER CONNECTOR , 1 X 4 PIN + 12V POWER CONNECTOR , 3 X M.2 SLOTS (KEY M ), 4 X SATA 6GB/S PORTS , 1 X USB 3.2 GEN 1 CONNECTOR (SUPPORTS USB TYPE-C) , 1 X USB 3.2 GEN 1 HEADER SUPPORT 2 ADDITIONAL USB 3.2 GEN 1 PORTS , 2 X USB 2.0 HEADERS SUPPORT 4 ADDITIONAL USB 2.0 PORTS , 3 X ADDRESSABLE GEN 2 HEADERS , 1 X AURA RGB HEADER ,1 X CLEAR CMOS HEADER , 1 X COM PORT HEADER , 1 X FRONT PANEL AUDIO HEADER (AAFP) , 1 X M.2 SLOT (KEY E) , 1 X S/PDIF OUT HEADER , 1 X SPI TPM HEADER (14-1) , 1 X 20-3 PIN SYSTEM PANEL HEADER WITH CHASSIS INTRUDE FUNCTION , 1 X THUNDERBOLT (USB4) HEADER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2X2 PORT (1 X USB TYPE-C) , 1 X USB 3.2 GEN 2 PORT (1 X TYPE-A) , 4 X USB 3.2 GEN 1 PORTS (4 X TYPE-A) , 2 X USB 2.0 PORTS (2 X TYPE-A) , 1 X DISPLAYPORT 1 X HDMI PORT , 1 X INTEL 1GB ETHERNET PORT , 3 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | DIGI+ VRM (- DIGITAL POWER DESIGN WITH DrMOS) , LANGUARD , OVERVOLTAGE PROTECTION , SAFESLOT CORE+ , STAINLESS STEEL BACK I/O , Q-DIMM , Q-LED CORE , Q SLOT , VRM HEATSINK DESIGN , PROCOOL , AURA RGB HEADER , ADDRESSABLE GEN 2 HEADERS |
