ASUS Z790-P WiFi CSM PRIME

The ASUS PRIME Z790-P WiFi CSM motherboard is designed to deliver exceptional performance, reliability, and scalability for 12th to 14th Gen Intel® Core™ processors. Engineered with ASUS Corporate Stable Model (CSM) support, this motherboard ensures long-term availability, enterprise-grade stability, and robust manageability for business and professional builds while offering versatile features for enthusiast users.

Key Features and Specifications

1. Processor & Chipset Support

• Socket: Intel® LGA1700

• CPU Support: 12th to 14th Gen Intel® Core™, Pentium® Gold, and Celeron® processors

• Chipset: Intel® Z790 for high-performance computing and overclocking capabilities

2. Memory

• Type: DDR5 memory

• Slots: 4 x DIMM, dual-channel architecture

• Capacity: Up to 128GB

• Speeds: Supports 7200+(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/4800 MT/s

• Intel XMP Support: Enables easy overclocking profiles

3. Expansion & Graphics

• PCIe Slots:

  • 1 x PCIe 5.0 x16 slot (CPU) for latest-generation GPUs

  • 2 x PCIe 4.0 x16 slots (x4 mode)

  • 1 x PCIe 3.0 x1 slot

• Multi-GPU Support: AMD CrossFireX™ technology

• Integrated Graphics: DisplayPort 1.4 and HDMI 2.1 outputs (CPU-dependent) for 4K UHD displays

4. Storage

• M.2 Slots:

  • 3 x M.2 PCIe 4.0 x4 slots for NVMe SSDs

• SATA:

  • 4 x SATA 6Gb/s ports supporting RAID 0, 1, 5, and 10

5. Networking & Wireless

• WiFi: WiFi 6 (802.11ax) with MU-MIMO support

• Bluetooth: Bluetooth® v5.3

• LAN: Intel® 2.5Gb Ethernet for high-speed wired connections

6. USB Connectivity

• Rear I/O:

  • 1 x USB 3.2 Gen 2x2 Type-C® (20Gbps)

  • 3 x USB 3.2 Gen 2 Type-A (10Gbps)

  • 2 x USB 2.0 ports

• Internal Headers:

  • USB 3.2 Gen 1 and USB 2.0 front-panel headers for additional connectivity

7. Audio

• Codec: Realtek 7.1 Surround Sound High Definition Audio

• Features: Audio shielding, premium capacitors, and dedicated PCB layers for clean audio output

8. Cooling & Power Design

• Power Stages: 14+1 DrMOS power stages with high-quality chokes and capacitors for stable power delivery

• Cooling:

  • VRM and PCH heatsinks

  • Hybrid fan headers with Fan Xpert 4 utility for precise cooling control

• ProCool Connector: Enhanced power connection for reduced impedance

9. Additional ASUS Enhancements

• CSM Support: Corporate Stable Model program for extended lifecycle and IT management

• ASUS OptiMem II: Improved memory signal integrity for better overclocking

• AI Overclocking & AI Cooling: Automated performance tuning and thermal optimization

• Q-LED Core & Q-DIMM/Q-Slot: Simplifies troubleshooting and component installation

• Aura Sync RGB: Customizable lighting with onboard RGB headers

Conclusion

The ASUS PRIME Z790-P WiFi CSM motherboard blends business-grade reliability with enthusiast-grade features. It supports the latest Intel CPUs, DDR5 memory, PCIe 5.0 GPUs, and high-speed connectivity while delivering exceptional stability, making it perfect for both enterprise systems and high-performance DIY builds.
