GIGABYTE B760 GAMING X AX DDR5
The GIGABYTE B760 GAMING X AX DDR5 motherboard supports Intel® 12th to 14th Gen CPUs, high-speed DDR5 memory, PCIe 4.0, dual M.2 slots, Wi-Fi 6E, 2.5GbE LAN, and robust cooling, delivering outstanding gaming performance with next-gen connectivity.
Features
The GIGABYTE B760 GAMING X AX DDR5 motherboard is a high-performance ATX platform designed for Intel® 12th to 14th Gen Core™ processors. Built on the Intel® B760 chipset, it combines next-generation DDR5 memory support, robust power delivery, and advanced connectivity to meet the needs of gamers and performance users alike.
Key Features and Specifications
CPU Support
-
Compatible with Intel® 12th to 14th Gen Core™, Pentium® Gold, and Celeron® processors on the LGA1700 socket.
-
Enhanced digital VRM design for stable CPU power delivery, ensuring reliable operation under gaming or heavy workloads.
Memory
-
Supports dual-channel DDR5 memory with speeds up to 7600 MT/s (OC).
-
Maximum capacity of 128GB, delivering greater bandwidth, improved stability, and efficiency compared to DDR4.
Expansion Slots
-
PCIe 4.0 x16 slot for high-bandwidth modern GPUs.
-
Additional PCIe slots for expansion cards and future upgrades.
Storage Options
-
Two PCIe 4.0 x4 M.2 slots for lightning-fast NVMe SSDs.
-
Four SATA III ports to support large-capacity HDDs or SSDs, providing versatile storage options.
Networking
-
Intel® Wi-Fi 6E for next-gen wireless connectivity with lower latency and higher throughput.
-
2.5GbE LAN for fast and stable wired networking.
Audio
-
High-quality HD audio subsystem with premium capacitors for clear sound, enhancing immersive gaming and entertainment.
Thermal Design
-
Large heatsinks and M.2 Thermal Guards prevent thermal throttling, keeping performance consistent even under heavy loads.
-
Optimized airflow design for long-lasting stability.
USB Connectivity
-
USB 3.2 Gen 2x2 Type-C for ultra-fast data transfers.
-
Multiple USB 3.2 Gen 2 / Gen 1 / USB 2.0 ports for a variety of peripheral devices.
Q-Flash Plus
-
Enables BIOS updates without installing CPU, memory, or GPU, ensuring seamless upgrades and compatibility.
RGB Fusion
-
Customizable RGB lighting zones, fully compatible with GIGABYTE RGB Fusion software for synchronized lighting effects.
Conclusion
The GIGABYTE B760 GAMING X AX DDR5 motherboard is a balanced combination of high-speed DDR5 performance, durable power delivery, efficient cooling, and next-generation connectivity. It’s an excellent choice for gamers, streamers, and PC builders looking for a future-ready Intel platform with premium features.
Specifications
| CPU | LGA1700 SOCKET SUPPORT FOR THE 14TH , 13TH AND 12TH GENERATION INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | SUPPORT FOR DDR5 7600(OC) / 7400(OC) /7200(OC) /7000(OC) /6800(OC) /6600(OC) /6400(OC) /6200(OC) /6000(OC) /5800(OC) /5600(OC) /5400(OC) /5200(OC) /4800 /4000 MT/s MEMORY MODULES |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5GBPS/1 GBPS/100 MBPS) , AMD WIFI 6E RZ608 (MT7921K) (PCB REV.1.0) , WIFI a,b,g,n,ac,ax ,SUPPORTING 2.4/5/6 GHz CARRIER FREQUNECY BANDS , BLUETOOTH 5.2 , SUPPORT FOR 11AX 80MHZ WIRELESS STANDARD, INTEL WIFI 6E AX210 (PCB REV. 1.1 ) , WIFI a,b,g,n,ac,ax , SUPPORTING 2.4/5/6 GHz CARRIER FREQUENCY BANDS , BLUETOOTH 5.3 , SUPPORT FOR 11AX 160MHz WIRELESS STANDARD , INTEL WIFI 6E AX211 (PCB REV1.2) , WIFI a,b,g,n,ac,ax, SUPPORTING 2.4/5/6 GHz CARRIER FREQUENCY BANDS , BLUETOOTH 5.3 , SUPPORT FOR 11AX 160MHz WIRELESS STANDARD , REALTEK WIFI 6E RTL8852CE (PCB REV. 1.3) , WIFI a,b,g,n,ac,ax, SUPPORTING 2.4/5/6 GHz CARRIER FREQUENCY BANDS , BLUETOOTH 5.3 SUPPORT FOR 11AX 160MHz WIRELESS STANDARD |
| AUDIO | REALTEK AUDIO CODEC , HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT , SUPPORTING PCIe 4.0 AND RUNNING AT X16 (PCIEX16) , 2 X PCI EXPRESS X16 SLOTS , SUPPORTING PCIe 3.0 AND RUNNING AT X1 (PCIEX1_1 , PCIEX1_2) |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (SOCKET 3 M KEY , TYPE 22110/2280 PCIe 4.0 X4/X2 SSD SUPPORT) (M2A_CPU) , 2 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 22110/2280 PCIe 4.0 X4/X2 SSD SUPPORT (M2P_SB, M2M_SB ) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24 PIN ATX MAIN POWER CONNECTOR , 1 X 8 PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER ,1 X CPU FAN/WATER COOLING PUMP HEADER , 3 X SYSTEM FAN HEADERS ,1 X SYSTEM FAN/WATER COOLING PUMP HEADER , 2 X ADDRESSABLE LED STRIP HEADER ,2 X RGB LED STRIP HEADERS , 3 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER ,1 X USB TYPE-C HEADER,WITH USB 3.2 GEN 2 SUPPORT , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 MODULE ONLY ) 1 X SERIAL PORT HEADER , 1 X Q-FLASH PLUS BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 1 X USB 3.2 GEN 2 TYPE-A PORT (RED) , 1 X USB TYPE-C PORT , WITH USB 3.2 GEN 1 SUPPORT , 1 X USB 3.2 GEN 1 PORT , 5 X USB 2.0/1.1 PORTS , 2 X SMA ANTENNA CONNECTORS (2T2R) , 1 X DISPLAY PORT , 1 X HDMI PORT , 1 X RJ-45 PORT , 6 X AUDIO JACKS |
| SIZE | FULL ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , AVAILABLE APPLICATIONS IN GCC MAY VARY BY MOTHERBOARD MODEL . SUPPORTED FUNCTIONS OF EACH APPLICATIONS MAY ALSO VARY DEPENDING ON MOTHERBOARD SPECIFICATIONS , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
