GIGABYTE B760M AORUS PRO AX DDR5
The GIGABYTE B760M AORUS PRO AX DDR5 is a premium micro-ATX motherboard supporting 12th to 14th Gen Intel® CPUs, DDR5 memory, PCIe 4.0, dual M.2 slots, Wi-Fi 6E, 2.5GbE LAN, advanced cooling, and customizable RGB Fusion.
Features
The GIGABYTE B760M AORUS PRO AX DDR5 is a high-performance micro-ATX motherboard designed for 12th to 14th Gen Intel® Core™, Pentium® Gold, and Celeron® processors on the LGA1700 socket. It delivers the perfect balance of power efficiency, connectivity, and next-generation performance for gamers, creators, and PC enthusiasts.
Key Features & Specifications:
-
Next-Gen Memory Support:
Supports DDR5 memory up to 128GB with speeds exceeding DDR5-7600 (OC), offering faster data transfer, enhanced stability, and improved efficiency. -
Robust Power Design:
Equipped with a 12+1+1 Twin Hybrid Digital VRM and premium chokes to ensure stable power delivery for multi-core CPUs under heavy workloads or gaming sessions. -
PCIe 4.0 Ready:
Features a reinforced PCIe x16 slot supporting the latest GPUs, along with dual PCIe 4.0/3.0 M.2 slots for ultra-fast NVMe SSDs with thermal guards to prevent throttling. -
Advanced Networking:
Integrated Intel Wi-Fi 6E and 2.5GbE LAN provide high-speed, low-latency networking for seamless gaming, streaming, and productivity. -
Comprehensive Cooling:
Includes large VRM heatsinks, M.2 thermal guards, and hybrid fan headers with Smart Fan 6 technology for efficient temperature management and silent operation. -
High-Definition Audio:
Premium Realtek HD Audio codec with high-end audio capacitors ensures crystal-clear sound and immersive gaming experiences. -
Connectivity Options:
-
USB 3.2 Gen 2 Type-C and Type-A ports for high-speed data transfer
-
HDMI and DisplayPort outputs for integrated graphics support
-
Multiple USB headers for expandability
-
-
Customization and RGB:
RGB Fusion 2.0 with addressable LED headers allows customizable lighting to sync with other AORUS components, enabling a fully personalized build. -
Ultra-Durable Build:
GIGABYTE’s Ultra Durable components, reinforced PCIe slots, and anti-sulfur resistors enhance durability and reliability for long-term use.
In summary, the GIGABYTE B760M AORUS PRO AX DDR5 combines next-gen DDR5 memory performance, robust power delivery, advanced connectivity, and premium cooling in a compact micro-ATX form factor, making it an excellent choice for high-performance gaming and content creation builds.
Specifications
| CPU | LGA1700 SOCKET SUPPORT FOR THE 14TH , 13TH AND 12TH GENERATION INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | SUPPORT FOR DDR5 7800(OC) /7600(OC) / 7400(OC) /7200(OC) /7000(OC) /6800(OC) /6600(OC) /6400(OC) /6200(OC) /6000(OC) /5800(OC) /5600(OC) /5400(OC) /5200(OC) /4800 /4000 MT/s MEMORY MODULES |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5GBPS/1 GBPS/100 MBPS) , WIFI a,b,g,n,ac,ax , SUPPORTING 2.4/5/6 GHz CARRIER FREQUENCY BANDS , BLUETOOTH , 5.3 , SUPPORT FOR 11AX 160MHz WIRELESS STANDARD AND UP TO 2.4 GBPS DATA RATE , RELATEK WIFI 6E RTL8852CE (PCB REV. 1.1) , WIFI a,b,g,n,ac,ax SUPPORTING 2.4/5/6 GHz CARRIER FREQUENCY BANDS , BLUETOOTH 5.3 , SUPPORT FOR 11AX 160MHz WIRELESS STANDARD AND UP TO 2.4 GBPS DATA RATE |
| AUDIO | REALTEK AUDIO CODEC , HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT , SUPPORTING PCIe 4.0 AND RUNNING AT X16 (PCIEX16) , 1 X PCI EXPRESS X16 SLOTS , SUPPORTING PCIe 3.0 AND RUNNING AT X4 (PCIEX4) |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (SOCKET 3 M KEY , TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT) (M2A_CPU) , 1 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 22110/2280 PCIe 4.0 X4/X2 SSD SUPPORT (M2P_SB ) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24 PIN ATX MAIN POWER CONNECTOR , 1 X 8 PIN ATX 12V POWER CONNECTOR ,1 X 4 PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER ,1 X CPU FAN/WATER COOLING PUMP HEADER , 3 X SYSTEM FAN HEADERS ,1 X SYSTEM FAN/WATER COOLING PUMP HEADER , 2 X ADDRESSABLE LED STRIP HEADER ,2 X RGB LED STRIP HEADERS , 2 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER ,1 X USB TYPE-C HEADER,WITH USB 3.2 GEN 2 SUPPORT , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 MODULE ONLY ) 1 X RESET BUTTON , 1 X Q-FLASH PLUS BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 1 X USB TYPE-C PORT , WITH USB 3.2 GEN 2X2 SUPPORT , 1 X USB 3.2 GEN 2 TYPE-A PORT (RED) , 3 X USB 3.2 GEN 1 PORTS , 4 X USB 2.0/1.1 PORTS , 2 X SMA ANTENNA CONNECTORS (2T2R) , 1 X HDMI PORT , 1 X DISPLAY PORT ,1 X RJ-45 PORT , 1 X OPTICAL S/PDIF OUT CONNECTOR , 2 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , AVAILABLE APPLICATIONS IN GCC MAY VARY BY MOTHERBOARD MODEL . SUPPORTED FUNCTIONS OF EACH APPLICATIONS MAY ALSO VARY DEPENDING ON MOTHERBOARD SPECIFICATIONS , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
