Features

The GIGABYTE B760M DS3H AX DDR4 motherboard is a compact and feature-rich micro-ATX solution designed to deliver a balance of performance, reliability, and connectivity for modern PC builds. It supports 12th to 14th Gen Intel® Core™, Pentium® Gold, and Celeron® processors using the LGA 1700 socket, making it ideal for gaming, productivity, and general-purpose computing.

Key Features:

1. Processor & Chipset Support

   • Compatible with Intel® 12th to 14th Gen processors.

   • Built on the Intel® B760 chipset for stable and efficient performance.

2. Memory Support

   • Dual-channel DDR4 memory architecture.

   • Supports up to 128GB DDR4 RAM with speeds up to 5333 MHz (OC) for faster multitasking and smooth application performance.

3. Expansion & Graphics

   • 1× PCIe 4.0 x16 slot for high-speed graphics cards.

   • 1× PCIe 3.0 x1 slot for additional expansion cards.

   • Integrated Intel® UHD Graphics support (when using compatible CPUs) with HDMI and DisplayPort outputs supporting up to 4K resolution.

4. Storage Options

   • 2× PCIe 4.0 x4 M.2 slots for high-speed NVMe SSDs.

   • 4× SATA 6Gb/s ports for additional storage devices.

   • Supports Intel® Optane™ Memory for enhanced responsiveness.

5. Networking & Wireless Connectivity

   • Wi-Fi 6 (802.11ax) and Bluetooth 5.2 for fast, stable wireless connections.

   • Realtek 2.5GbE LAN for high-bandwidth wired networking.

6. USB Connectivity

   • Multiple USB ports including USB 3.2 Gen1 Type-A and USB 2.0.

   • Internal headers for additional front-panel USB connectivity.

7. Audio

   • High-quality Realtek Audio Codec providing immersive HD audio for gaming and entertainment.

8. Thermal Design & Durability

   • Smart Fan 6 technology with multiple temperature sensors and hybrid fan headers for optimized cooling.

   • Ultra Durable™ design featuring high-quality components, solid power delivery, and surge protection for long-term reliability.

9. BIOS & Ease of Use

   • User-friendly GIGABYTE UEFI BIOS with advanced tuning options.

   • Q-Flash Plus allows BIOS updates without installing CPU, memory, or GPU.

Specifications (Summary):

• Form Factor: Micro-ATX

• Socket: LGA 1700

• Chipset: Intel® B760

• Memory: 2× DDR4 DIMM, up to 128GB, 5333 MHz (OC)

• Storage: 2× M.2 (PCIe 4.0), 4× SATA 6Gb/s

• Graphics Outputs: HDMI, DisplayPort (integrated graphics required)

• Networking: Intel® Wi-Fi 6, Realtek 2.5Gb LAN

• USB Ports: Rear and internal USB 3.2 Gen1 / USB 2.0

• Audio: High Definition Audio Codec

• Expansion Slots: 1× PCIe 4.0 x16, 1× PCIe 3.0 x1
