GIGABYTE B760M G AX DDR5
The GIGABYTE B760M G AX DDR5 is a micro-ATX motherboard supporting Intel 12th to 14th Gen CPUs, dual-channel DDR5, PCIe 4.0, Wi-Fi 6, 2.5GbE LAN, dual M.2 slots, and durable power delivery with Smart Fan 6.
Features
Gigabyte B760M G AX DDR5 – Compact, Reliable, and Ready for Next-Gen Performance
The Gigabyte B760M G AX DDR5 is a feature-rich micro-ATX motherboard designed for Intel’s 12th to 14th Gen Core processors. Built with advanced connectivity, next-gen memory support, and reliable power delivery, it offers a balanced platform for gaming, content creation, and productivity in a compact form factor.
Key Features
1. Latest Intel Platform
-
Supports Intel 12th to 14th Gen Core, Pentium Gold, and Celeron processors with LGA 1700 socket.
-
Optimized design for improved power efficiency and stable system performance.
2. High-Speed DDR5 Memory
-
Dual-channel DDR5 support with speeds up to 5600+ MHz (OC).
-
Supports up to 128GB memory capacity and Intel XMP 3.0 profiles for easy memory tuning.
3. PCIe 4.0 Ready
-
PCIe 4.0 x16 slot for high-performance GPUs.
-
Two PCIe 4.0 M.2 slots enable ultra-fast NVMe SSD storage with maximum bandwidth.
4. Advanced Networking
-
Intel Wi-Fi 6 (802.11ax) with high-speed wireless connectivity and reduced latency.
-
2.5GbE LAN ensures fast and stable wired networking for gaming or large data transfers.
5. Comprehensive Connectivity
-
Multiple USB 3.2 Gen1 and USB 2.0 ports for high-speed peripherals.
-
HDMI and DisplayPort outputs support 4K resolution with integrated graphics.
6. Efficient Thermal Design
-
M.2 thermal guards prevent overheating and SSD performance throttling.
-
VRM heatsinks maintain stable temperatures even under sustained loads.
7. Ultra Durable Build Quality
-
6+2+1 phase digital VRM design ensures clean and efficient power delivery.
-
Reinforced PCIe slot and solid pin power connectors provide added durability.
8. Smart Fan 6 Technology
-
Hybrid fan headers with intelligent control keep the system cool and quiet.
-
Temperature sensors across the board allow precise fan curve customization.
9. Easy BIOS Updates with Q-Flash Plus
-
Update BIOS without CPU, memory, or graphics card installation, ensuring hassle-free maintenance.
In Summary:
The Gigabyte B760M G AX DDR5 motherboard delivers next-gen DDR5 performance, PCIe 4.0 support, Wi-Fi 6, and robust durability in a compact micro-ATX form factor. It’s an excellent foundation for building a reliable, high-performance gaming or productivity PC.
Specifications
| CPU | LGA1700 SOCKET SUPPORT FOR THE 14TH , 13TH AND 12TH GENERATION INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | SUPPORT FOR DDR5 8000(OC) /7800(OC) /7600(OC) / 7400(OC) /7200(OC) /7000(OC) /6800(OC) /6600(OC) /6400(OC) /6200(OC) /6000(OC) /5800(OC) /5600(OC) /5400(OC) /5200(OC) /4800 /4400 MT/s MEMORY MODULES |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5GBPS/1 GBPS/100 MBPS) , INTEL WIFI 6E AX211 , WIFI a,b,g,n,ac,ax, SUPPORTING 2.4/5/6 GHZ CARRIER FREQUENCY BANDS , BLUETOOTH 5.3 , SUPPORT FOR 11AX 160MHz WIRELESS STANDARD |
| AUDIO | REALTEK AUDIO CODEC , HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT , SUPPORTING PCIe 4.0 AND RUNNING AT X16 ,1 X PCI EXPRESS X1 SLOTS , SUPPORTING PCIe 3.0 AND RUNNING AT X |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (SOCKET 3 M KEY , TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT) (M2A_CPU) , 1 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT (M2P_SB ) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24 PIN ATX MAIN POWER CONNECTOR , 1 X 8 PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER , 3 X SYSTEM FAN HEADERS , 2 X ADDRESSABLE LED STRIP HEADER ,1 X RGB LED STRIP HEADERS , 2 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 MODULE ONLY ) 1 X S/PDIF OUT HEADER ,1 X SERIAL PORT HEADER , 1 X Q-FLASH PLUS BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 2 X USB 2.0/1.1 PORTS , 1 X PS/2 KEYBOARD/MOUSE PORT, 2 X SMA ANTENNA CONNECTORS (1T1R)/ (2T2R) (NOTE) jkl ,1 X D-SUB PORT, 1 X HDMI PORT , 1 X DISPLAYPORTS , 3 X USB 3.2 GEN 1 PORTS , 1 X USB TYPE-C PORT, WITH USB 3.2 GEN 1 SUPPORT , 1 X RJ-45 PORT , 3 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , AVAILABLE APPLICATIONS IN GCC MAY VARY BY MOTHERBOARD MODEL . SUPPORTED FUNCTIONS OF EACH APPLICATIONS MAY ALSO VARY DEPENDING ON MOTHERBOARD SPECIFICATIONS , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
