GIGABYTE B760M GAMING DDR5
The GIGABYTE B760M GAMING DDR5 motherboard supports Intel 12th to 14th Gen CPUs, offers high-speed DDR5 memory, PCIe 4.0 expansion, dual M.2 slots, enhanced audio, solid power delivery, and reliable thermal design for immersive gaming performance.
Features
The GIGABYTE B760M GAMING DDR5 motherboard is designed to deliver an excellent balance of performance, stability, and gaming-focused features for Intel’s 12th to 14th Gen Core processors. Built on the B760 chipset, this micro-ATX board combines next-generation connectivity, high-speed DDR5 memory support, and advanced cooling solutions, making it ideal for gamers and PC enthusiasts seeking a compact yet powerful build.
Key Features & Specifications:
1. CPU Support
-
Compatible with Intel 12th to 14th Gen Core, Pentium Gold, and Celeron processors
-
LGA 1700 socket for maximum performance and efficiency
2. Memory
-
Supports DDR5 memory up to high frequencies with XMP profiles
-
Dual-channel architecture for improved bandwidth and responsiveness
3. Expansion & Storage
-
PCIe 4.0 x16 slot for next-gen graphics cards with high bandwidth
-
Dual PCIe 4.0/3.0 M.2 slots for ultra-fast NVMe SSDs
-
Multiple SATA 6Gb/s ports for additional storage flexibility
4. Connectivity
-
Intel Wi-Fi 6 module for faster wireless networking with lower latency
-
2.5GbE LAN providing high-speed wired connectivity
-
Rear I/O with multiple USB 3.2 Gen 1/Gen 2 ports and USB Type-C support
5. Audio & Gaming Enhancements
-
High-definition 8-channel audio with advanced audio capacitors for immersive sound
-
Noise guard technology to minimize interference during gameplay
6. Thermal Design & Power Delivery
-
Enhanced VRM design ensures stable power delivery for high-performance CPUs
-
Enlarged heatsinks on critical components to maintain optimal temperatures
-
Hybrid fan headers with Smart Fan 6 for advanced cooling control
7. Build Quality & Aesthetics
-
Ultra Durable components for long-lasting reliability
-
Reinforced PCIe slot to support heavier GPUs
-
Sleek black PCB with gaming-focused design accents
Conclusion:
The GIGABYTE B760M GAMING DDR5 is an ideal solution for building a compact yet high-performance gaming PC. With DDR5 memory support, PCIe 4.0 expansion, dual M.2 storage, and integrated Wi-Fi 6, it delivers the speed, stability, and connectivity modern gamers demand.
Specifications
| CPU | LGA1700 SOCKET SUPPORT FOR THE 14TH , 13TH AND 12TH GENERATION INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | 2 x DIMM RAM SLOTS SUPPORT FOR DDR5 8000(OC) /7800(OC) /7600(OC) / 7400(OC) /7200(OC) /7000(OC) /6800(OC) /6600(OC) /6400(OC) /6200(OC) /6000(OC) /5800(OC) /5600(OC) /5400(OC) /5200(OC) /4800 /4000 MT/s MEMORY MODULES |
| VIDEO OUTPUT PORTS | 1 X VGA, 1 X HDMI PORT AND 1 X DISPLAY PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5GBPS/1 GBPS/100 MBPS) |
| AUDIO | REALTEK AUDIO CODEC , HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT , SUPPORTING PCIe 4.0 AND RUNNING AT X16 ,1 X PCI EXPRESS X1 SLOTS , SUPPORTING PCIe 3.0 AND RUNNING AT X1 |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (SOCKET 3 M KEY , TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT) (M2A_CPU) , 1 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT (M2P_SB ) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24 PIN ATX MAIN POWER CONNECTOR , 1 X 8 PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER , 3 X SYSTEM FAN HEADERS , 1 X ADDRESSABLE LED STRIP HEADER ,1 X RGB LED STRIP HEADERS , 2 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 MODULE ONLY ) 1 X S/PDIF OUT HEADER ,1 X SERIAL PORT HEADER , 1 X Q-FLASH PLUS BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 2 X USB 2.0/1.1 PORTS , 1 X PS/2 KEYBOARD/MOUSE PORT ,1 X D-SUB PORT, 1 X HDMI PORT , 1 X DISPLAYPORTS , 3 X USB 3.2 GEN 1 PORTS , 1 X USB TYPE-C PORT, WITH USB 3.2 GEN 1 SUPPORT , 1 X RJ-45 PORT , 3 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , AVAILABLE APPLICATIONS IN GCC MAY VARY BY MOTHERBOARD MODEL . SUPPORTED FUNCTIONS OF EACH APPLICATIONS MAY ALSO VARY DEPENDING ON MOTHERBOARD SPECIFICATIONS , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
