Features

Overview

The GIGABYTE H410M H V2 is a micro-ATX motherboard designed for 10th and 11th Generation Intel Core, Pentium Gold, and Celeron processors on the LGA 1200 socket. It delivers essential performance, durability, and connectivity features for entry-level and budget-friendly PC builds, making it an excellent choice for everyday computing, office use, and light gaming.

Key Features

1. CPU & Chipset Support

• Supports Intel 10th and 11th Gen processors with up to 65W TDP.

• Built on the Intel H410 chipset, offering reliable and efficient system operation.

2. Memory

• 2 x DDR4 DIMM slots with dual-channel architecture.

• Supports up to 64 GB DDR4 memory at speeds up to 2933 MHz (with Intel Core i7/i9 CPUs).

• Memory performance optimized for stable multitasking and responsive applications.

3. Expansion & Graphics

• 1 x PCIe 3.0 x16 slot for graphics cards.

• 1 x PCIe 3.0 x1 slot for expansion cards.

• Integrated Intel UHD Graphics support with display outputs:

  • 1 x HDMI port (up to 4K resolution at 30Hz).

  • 1 x D-Sub (VGA) port (up to 1920x1200 resolution).

4. Storage

• 1 x M.2 slot (PCIe 3.0 x4/SATA) for high-speed NVMe or SATA SSDs.

• 4 x SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support.

5. Networking & Audio

• Integrated Realtek Gigabit LAN for stable, high-speed wired networking.

• Realtek 7.1-channel HD Audio codec delivering crisp sound quality for multimedia and entertainment.

6. Connectivity & Rear I/O

• USB Ports:

  • 4 x USB 3.2 Gen 1 (rear panel + headers).

  • 6 x USB 2.0 (rear panel + headers).

• Audio jacks for 7.1 surround sound.

• PS/2 combo port for legacy keyboard/mouse support.

• LAN port with anti-surge protection.

7. Cooling & Reliability

• Equipped with Smart Fan 5 technology for intelligent cooling and fan control.

• Multiple temperature sensors and hybrid fan headers ensure efficient thermal management.

• High-quality capacitors and solid pin power connectors for durability and stable power delivery.

8. BIOS & Software

• Features Q-Flash utility for BIOS updates without needing an operating system.

• User-friendly BIOS interface for easy setup and system customization.

9. Form Factor & Build

• Micro-ATX form factor (22.6cm x 18.5cm), compact and compatible with most budget or office PC cases.

• Ultra-durable design with reinforced PCB and humidity protection.

Conclusion

The GIGABYTE H410M H V2 is a reliable, cost-effective motherboard for users who need essential features without unnecessary extras. With support for 10th Gen Intel CPUs, DDR4 memory, M.2 storage, Gigabit LAN, and Smart Fan 5, it provides a solid foundation for building efficient home or office PCs with dependable performance and stability.
