Features

The GIGABYTE H510M H is a Micro-ATX motherboard designed for 10th and 11th Generation Intel Core, Pentium Gold, and Celeron processors with the LGA 1200 socket. Offering a balance of performance, expandability, and durability, it’s ideal for building cost-effective desktop PCs for home, office, and entry-level gaming.

Processor & Chipset Support

• Compatible with 10th Gen and 11th Gen Intel CPUs.

• Based on the Intel H510 chipset, ensuring efficient and stable performance for mainstream systems.

Memory

• 2 x DDR4 DIMM slots with dual-channel architecture.

• Supports up to 64 GB DDR4 RAM.

• Maximum memory speed: 3200 MHz (11th Gen) / 2933 MHz (10th Gen Core i9/i7) / 2666 MHz (10th Gen Core i5/i3/Pentium/Celeron).

Expansion & Graphics

• 1 x PCIe 4.0 x16 slot (11th Gen CPUs only).

• 1 x PCIe 3.0 x1 slot for add-on expansion.

• Integrated graphics support through Intel UHD Graphics with outputs:

  • 1 x HDMI port (4K resolution at 60Hz).

  • 1 x D-Sub (VGA) port (1920x1200 resolution).

Storage

• 1 x M.2 slot (PCIe 3.0 x4/SATA) for high-speed SSDs.

• 4 x SATA 6Gb/s ports supporting RAID 0, 1, 5, and 10 configurations.

Networking & Audio

• Integrated Realtek Gigabit LAN for fast and stable network connections.

• Realtek 7.1-channel HD Audio codec for clear and immersive sound.

Connectivity & Rear I/O

• USB Ports:

  • 4 x USB 3.2 Gen 1.

  • 6 x USB 2.0.

• Rear Panel Includes:

  • 1 x HDMI port.

  • 1 x D-Sub port.

  • 3 x Audio jacks.

  • 1 x PS/2 combo port.

  • 1 x RJ-45 Gigabit LAN port.

Cooling & Durability

• Smart Fan 5 technology with multiple sensors and hybrid fan headers.

• Fan Stop feature for silent operation under low load.

• Ultra Durable design with high-quality capacitors, solid pin power connectors, humidity, and surge protection.

BIOS & Utility

• Q-Flash support for BIOS updates without requiring Windows installation.

• Intuitive and easy-to-navigate BIOS interface.

Form Factor & Build

• Compact Micro-ATX form factor (22.6 cm x 18.5 cm).

• Designed for compatibility with a wide range of PC cases.

Conclusion

The GIGABYTE H510M H provides a solid foundation for everyday computing and light gaming. With support for 11th Gen CPUs, DDR4 dual-channel memory, M.2 SSDs, Gigabit LAN, and Smart Fan 5, it delivers durability, stability, and performance at an affordable price.
