Features

The GIGABYTE H510M S2 V2 is a Micro-ATX motherboard designed for 10th and 11th Generation Intel Core, Pentium Gold, and Celeron processors using the LGA 1200 socket. Built with Intel’s H510 chipset, it delivers stable, efficient performance and essential features for affordable home, office, and entry-level gaming PCs.

Processor & Chipset Support

• Compatible with 10th and 11th Gen Intel CPUs.

• Powered by the Intel H510 chipset, optimized for dependable everyday computing.

Memory

• 2 x DDR4 DIMM slots, supporting dual-channel memory architecture.

• Maximum capacity: 64 GB DDR4 RAM.

• Memory speeds supported:

  • 3200 MHz (11th Gen CPUs)

  • 2933 MHz (10th Gen Core i9/i7)

  • 2666 MHz (10th Gen Core i5/i3/Pentium/Celeron)

Expansion & Graphics

• 1 x PCIe 4.0 x16 slot (when paired with 11th Gen CPUs).

• 1 x PCIe 3.0 x1 slot for additional expansion cards.

• Integrated Intel UHD Graphics support with outputs:

  • 1 x HDMI port (up to 4K resolution at 60Hz).

  • 1 x D-Sub (VGA) port (up to 1920x1200 resolution).

Storage

• 1 x M.2 slot (PCIe 3.0 x4/SATA) for high-speed NVMe or SATA SSDs.

• 4 x SATA 6Gb/s ports, supporting RAID 0, 1, 5, and 10.

Networking & Audio

• Integrated Realtek Gigabit LAN for fast and stable networking.

• Realtek 7.1-channel HD Audio codec for rich, clear sound.

Connectivity & Rear I/O

• USB Ports:

  • 4 x USB 3.2 Gen 1.

  • 6 x USB 2.0.

• Rear Panel Includes:

  • 1 x HDMI port.

  • 1 x D-Sub port.

  • 3 x Audio jacks.

  • 1 x PS/2 combo port for legacy devices.

  • 1 x RJ-45 Gigabit LAN port.

Cooling & Durability

• Smart Fan 5 technology with multiple temperature sensors.

• Hybrid fan headers for both PWM and voltage fans.

• Fan Stop feature for silent operation when cooling demand is low.

• Ultra Durable build quality, including solid pin connectors, anti-surge, and humidity protection for longer lifespan.

BIOS & Utility

• Q-Flash support for easy BIOS updates without requiring Windows.

• Simple, user-friendly BIOS interface for customization.

Form Factor & Build

• Micro-ATX form factor (22.6 cm x 18.5 cm).

• Compact design suitable for small cases while retaining expandability.

Conclusion

The GIGABYTE H510M S2 V2 is an excellent choice for building cost-effective systems. With support for 11th Gen Intel CPUs, DDR4 dual-channel memory, M.2 SSDs, Gigabit LAN, and Smart Fan 5, it ensures stability, durability, and smooth everyday performance.
