Features

The GIGABYTE H610M H DDR5 is a Micro-ATX motherboard built for 12th to 14th Generation Intel Core, Pentium Gold, and Celeron processors with the LGA 1700 socket. Powered by the Intel H610 chipset, it combines affordability with modern features, making it ideal for office systems, everyday desktops, and entry-level gaming builds.

Processor & Chipset Support

• Supports 12th Gen to 14th Gen Intel CPUs.

• Powered by the Intel H610 chipset for efficient system performance and reliability.

Memory

• 2 x DDR5 DIMM slots with dual-channel architecture.

• Supports up to 64 GB DDR5 RAM.

• Memory speeds supported up to 4800 MHz (OC support varies by CPU).

Expansion & Graphics

• 1 x PCIe 4.0 x16 slot for graphics cards.

• 1 x PCIe 3.0 x1 slot for additional expansion.

• Integrated Intel UHD Graphics with outputs:

  • 1 x HDMI port (up to 4K resolution at 60Hz).

  • 1 x D-Sub (VGA) port (up to 1920x1200 resolution).

Storage

• 1 x M.2 slot (PCIe 3.0 x4/SATA) for high-speed NVMe SSDs.

• 4 x SATA 6Gb/s ports for additional SSDs and HDDs.

Networking & Audio

• Integrated Realtek Gigabit LAN for stable wired connectivity.

• Realtek 8-channel HD Audio codec provides clear and immersive sound quality.

Connectivity & Rear I/O

• USB Ports:

  • 4 x USB 3.2 Gen 1.

  • 6 x USB 2.0.

• Rear Panel Includes:

  • HDMI and D-Sub ports for display.

  • 3 x Audio jacks.

  • 1 x RJ-45 Gigabit LAN port.

  • 1 x PS/2 combo port for keyboard or mouse.

Cooling & Durability

• Smart Fan 6 technology with multiple temperature sensors and hybrid fan headers.

• Fan Stop feature for quieter, efficient operation under low loads.

• Ultra Durable design, including solid pin power connectors, high-quality capacitors, humidity, and surge protection.

BIOS & Utility

• Q-Flash support for easy BIOS updates without entering an operating system.

• User-friendly BIOS for simple configuration and customization.

Form Factor & Build

• Micro-ATX form factor (22.6 cm x 18.5 cm).

• Compact design ensures compatibility with smaller cases without sacrificing essential features.

Conclusion

The GIGABYTE H610M H DDR5 brings next-generation performance to budget builds with DDR5 memory support, PCIe 4.0, M.2 storage, Gigabit LAN, and Smart Fan 6. It is a durable and efficient choice for modern everyday computing.
