Features

The GIGABYTE Z690 AORUS ELITE AX DDR4 is a high-performance ATX motherboard built for 12th to 14th Gen Intel Core processors using the LGA 1700 socket. Designed on the Intel Z690 chipset, it combines cutting-edge features, robust power delivery, and advanced cooling to provide a rock-solid foundation for gaming, overclocking, and heavy workloads.

Processor & Chipset Support

• Supports 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors.

• Built on the Intel Z690 chipset with full support for advanced performance tuning.

Memory

• 4 x DDR4 DIMM slots with dual-channel architecture.

• Supports up to 128 GB DDR4 RAM.

• Memory speeds up to 5333 MHz (OC) for overclocking enthusiasts.

Expansion & Graphics

• 1 x PCIe 5.0 x16 slot with reinforced design for modern GPUs.

• 2 x PCIe 3.0 x16 slots (operating at x4).

• Multi-GPU support via AMD CrossFire.

• Integrated Intel UHD Graphics support with outputs:

  • 1 x HDMI 2.1 port (up to 4K resolution at 60Hz).

Storage

• 4 x M.2 PCIe 4.0 x4 slots with thermal guards for ultra-fast NVMe SSDs.

• 6 x SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support.

Networking & Wireless

• Integrated Intel 2.5GbE LAN for high-speed wired networking.

• Intel Wi-Fi 6 802.11ax + Bluetooth 5.2 for fast, stable wireless connectivity.

Audio

• High-quality Realtek ALC1220-VB HD Audio codec with studio-grade sound.

• Audiophile-grade capacitors ensure premium sound clarity.

Connectivity & Rear I/O

• USB Ports:

  • 1 x USB 3.2 Gen 2x2 Type-C.

  • 3 x USB 3.2 Gen 2 Type-A.

  • 6 x USB 3.2 Gen 1.

  • 8 x USB 2.0.

• Rear panel includes:

  • 1 x HDMI port.

  • 1 x RJ-45 2.5GbE LAN port.

  • 2 x Antenna connectors for Wi-Fi 6.

  • 5 x Audio jacks + Optical S/PDIF out.

Cooling & Durability

• Advanced Thermal Design with enlarged heatsinks, multi-layered thermal guards, and optimized airflow.

• Smart Fan 6 technology with multiple temperature sensors and hybrid fan headers.

• Ultra Durable build quality, with reinforced PCIe slots, solid pin connectors, anti-sulfur resistors, and enhanced PCB protection.

BIOS & Utilities

• Q-Flash Plus for BIOS updates without CPU, RAM, or GPU installed.

• User-friendly BIOS with easy tuning options for overclocking and system stability.

• AORUS software suite for monitoring, lighting control, and performance adjustments.

Form Factor & Build

• ATX form factor (30.5 cm x 24.4 cm).

• Sleek black design with customizable RGB Fusion 2.0 lighting for stylish builds.

Conclusion

The GIGABYTE Z690 AORUS ELITE AX DDR4 offers gamers and professionals an excellent balance of performance, durability, and connectivity. With DDR4 memory support, PCIe 5.0, M.2 Gen4 storage, Wi-Fi 6, and advanced cooling, it’s an outstanding choice for high-performance desktop systems.
