Features

The GIGABYTE Z790 AORUS MASTER is a premium E-ATX motherboard built for 12th to 14th Gen Intel Core processors on the LGA 1700 socket. Powered by the Intel Z790 chipset, it offers cutting-edge features, world-class connectivity, and outstanding durability, making it an ideal choice for enthusiasts, creators, and gamers seeking uncompromising performance.

Processor & Chipset Support

• Compatible with 12th to 14th Gen Intel Core, Pentium Gold, and Celeron processors.

• Fully supports overclocking with the Intel Z790 chipset.

Memory

• 4 x DDR5 DIMM slots with dual-channel support.

• Supports up to 192 GB DDR5 RAM.

• Extreme memory speeds up to 8000 MHz (OC) for next-gen performance.

Expansion & Graphics

• 1 x PCIe 5.0 x16 slot with reinforced shielding for modern GPUs.

• 2 x PCIe 4.0 x16 slots (operating at x4).

• Integrated Intel UHD Graphics support (CPU dependent) with:

  • 1 x HDMI 2.1 port (up to 4K at 60Hz).

Storage

• 5 x M.2 slots including PCIe 5.0 x4 and PCIe 4.0 x4 with full thermal coverage.

• 6 x SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support.

Networking & Wireless

• Marvell AQtion 10GbE LAN for lightning-fast wired networking.

• Intel Wi-Fi 6E 802.11ax + Bluetooth 5.3 for advanced wireless connectivity.

Audio

• ESS SABRE Hi-Fi 9118 DAC paired with a premium Realtek ALC1220-VB codec.

• Audiophile-grade capacitors for high-resolution, studio-quality sound.

Connectivity & Rear I/O

• USB Ports:

  • 1 x USB 3.2 Gen 2x2 Type-C.

  • 4 x USB 3.2 Gen 2 Type-A.

  • 4 x USB 3.2 Gen 1.

  • 4 x USB 2.0.

• Rear panel includes:

  • 1 x HDMI port.

  • 1 x RJ-45 10GbE LAN port.

  • 2 x Antenna connectors (Wi-Fi 6E).

  • 5 x Audio jacks + Optical S/PDIF out.

Cooling & Durability

• Thermal Reactive Armor with enlarged heatsinks, nanocarbon coating, and multi-layered M.2 thermal shields.

• Smart Fan 6 technology with multiple hybrid fan headers and temperature sensors.

• Ultra Durable design with PCIe reinforcement, solid pin connectors, and high-quality PCB layers for stability.

BIOS & Utilities

• Q-Flash Plus for BIOS updates without installing CPU, RAM, or GPU.

• User-friendly BIOS with advanced tuning and overclocking options.

• AORUS software suite including RGB Fusion 2.0, system monitoring, and optimization tools.

Form Factor & Build

• E-ATX form factor (30.5 cm x 26.9 cm).

• Premium design with integrated RGB Fusion lighting zones for customizable aesthetics.

Conclusion

The GIGABYTE Z790 AORUS MASTER is engineered for enthusiasts demanding the best. With DDR5, PCIe 5.0, Gen5 M.2 storage, 10GbE LAN, Wi-Fi 6E, and superior thermal solutions, it delivers world-class gaming, content creation, and workstation performance.
