Features

The GIGABYTE Z790 D AX is a versatile ATX motherboard designed for 12th, 13th, and 14th Gen Intel Core processors on the LGA 1700 socket. Powered by the Intel Z790 chipset, it delivers high-speed connectivity, advanced cooling, and future-ready features, making it an excellent choice for gaming, productivity, and mainstream high-performance systems.

Processor & Chipset Support

• Compatible with 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron processors.

• Built on the Intel Z790 chipset, supporting overclocking and advanced tuning.

Memory

• 4 x DDR5 DIMM slots with dual-channel architecture.

• Supports up to 192 GB DDR5 memory.

• Extreme speeds up to 7600 MHz (OC) for cutting-edge performance.

Expansion & Graphics

• 1 x PCIe 5.0 x16 slot with reinforced protection for high-performance GPUs.

• 1 x PCIe 4.0 x16 slot (x4 mode).

• 2 x PCIe 3.0 x1 slots for additional cards.

• Integrated Intel UHD Graphics support (CPU dependent) with:

  • 1 x HDMI 2.1 port (up to 4K at 60Hz).

  • 1 x DisplayPort 1.2.

Storage

• 3 x M.2 slots (PCIe 4.0 x4) with dedicated heatsinks.

• 4 x SATA 6Gb/s ports supporting RAID 0, 1, 5, and 10.

Networking & Wireless

• Intel 2.5GbE LAN for high-speed wired networking.

• Intel Wi-Fi 6E 802.11ax + Bluetooth 5.3 for seamless wireless connectivity.

Audio

• Realtek ALC897/ALC1220-VB HD Audio codec (varies by revision).

• High-quality capacitors for crisp and immersive sound output.

Connectivity & Rear I/O

• USB Ports:

  • 1 x USB 3.2 Gen 2x2 Type-C.

  • 2 x USB 3.2 Gen 2 Type-A.

  • 4 x USB 3.2 Gen 1.

  • 4 x USB 2.0.

• Rear panel includes:

  • 1 x HDMI port.

  • 1 x DisplayPort.

  • 1 x RJ-45 2.5GbE LAN port.

  • 2 x Antenna connectors (Wi-Fi 6E).

  • 3 x Audio jacks.

Cooling & Durability

• Advanced Thermal Design with extended heatsinks and thermal guards for M.2 drives.

• Smart Fan 6 with multiple temperature sensors and hybrid fan headers.

• Ultra Durable construction featuring solid pin power connectors and reinforced PCIe slots.

BIOS & Utilities

• Q-Flash Plus allows BIOS updates without CPU, RAM, or GPU.

• User-friendly BIOS with customizable overclocking and tuning options.

• GIGABYTE Control Center (GCC) for system monitoring, RGB Fusion, and performance optimization.

Form Factor & Build

• ATX form factor (30.5 cm x 24.4 cm).

• Sleek black PCB design with RGB Fusion lighting support for customizable aesthetics.

Conclusion

The GIGABYTE Z790 D AX is a balanced and reliable motherboard offering DDR5 support, PCIe 5.0, Gen4 M.2 storage, Wi-Fi 6E, and robust cooling. It’s perfect for gamers and creators seeking performance and durability in a modern system.
