Features

The GIGABYTE Z790 EAGLE AX is a well-rounded ATX motherboard built for 12th, 13th, and 14th Gen Intel Core processors on the LGA 1700 socket. Based on the Intel Z790 chipset, it provides next-generation DDR5 support, fast PCIe 5.0 expansion, and Wi-Fi 6E, delivering excellent performance for gaming, productivity, and future-proof PC builds.

Processor & Chipset Support

• Supports 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron processors.

• Powered by the Intel Z790 chipset, enabling advanced performance and tuning.

Memory

• 4 x DDR5 DIMM slots with dual-channel support.

• Maximum capacity up to 192 GB DDR5.

• High-speed memory support up to 7600 MHz (OC).

Expansion & Graphics

• 1 x PCIe 5.0 x16 slot with reinforced design for next-gen GPUs.

• 1 x PCIe 4.0 x16 slot (x4 mode).

• 2 x PCIe 3.0 x1 slots.

• Integrated Intel UHD Graphics support (CPU dependent) with:

  • 1 x HDMI 2.1 port (up to 4K at 60Hz).

  • 1 x DisplayPort 1.2.

Storage

• 3 x M.2 PCIe slots (1 x PCIe 5.0 x4, 2 x PCIe 4.0 x4) with thermal protection.

• 4 x SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support.

Networking & Wireless

• Intel 2.5GbE LAN for fast wired networking.

• Intel Wi-Fi 6E 802.11ax + Bluetooth 5.3 for stable, next-gen wireless connectivity.

Audio

• Realtek ALC897 HD Audio codec.

• High-quality audio capacitors for clear and immersive sound output.

Connectivity & Rear I/O

• USB Ports:

  • 1 x USB 3.2 Gen 2x2 Type-C.

  • 2 x USB 3.2 Gen 2 Type-A.

  • 4 x USB 3.2 Gen 1.

  • 4 x USB 2.0.

• Rear panel includes:

  • 1 x HDMI port.

  • 1 x DisplayPort.

  • 1 x RJ-45 2.5GbE LAN port.

  • 2 x Antenna connectors (Wi-Fi 6E).

  • 3 x Audio jacks.

Cooling & Durability

• Enhanced Thermal Design with extended heatsinks and M.2 thermal guards.

• Smart Fan 6 technology with multiple hybrid fan headers and sensors.

• Ultra Durable build quality with reinforced slots, solid pin connectors, and multi-layer PCB protection.

BIOS & Utilities

• Q-Flash Plus for BIOS updates without CPU, RAM, or GPU installed.

• Advanced and easy-to-use BIOS with tuning and overclocking options.

• GIGABYTE Control Center software for system monitoring, lighting control, and optimization.

Form Factor & Build

• ATX form factor (30.5 cm x 24.4 cm).

• Sleek, gamer-oriented PCB design with RGB Fusion lighting support for customizable aesthetics.

Conclusion

The GIGABYTE Z790 EAGLE AX combines performance, efficiency, and affordability in one package. With DDR5 memory support, PCIe 5.0, Gen4 M.2 storage, Wi-Fi 6E, and reliable cooling, it’s an excellent choice for gamers and creators building a modern, future-ready system.
