Features

The GIGABYTE Z790 GAMING X is a performance-focused ATX motherboard built around the Intel Z790 chipset and LGA1700 socket, engineered to provide gamers and creators with next-generation memory, storage, and connectivity. It blends durability, speed, and affordability, making it ideal for mid-to-high-end gaming systems.

Processor & Chipset Support

• Compatible with 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron processors.

• Based on the Intel Z790 chipset, enabling advanced tuning and stable overclocking.

Memory

• 4 x DDR5 DIMM slots with dual-channel support.

• Supports up to 192 GB DDR5 memory.

• High-speed overclocked memory up to 7600 MHz (OC) for maximum performance.

Expansion & Graphics

• 1 x PCIe 5.0 x16 slot reinforced for high-performance graphics cards.

• 1 x PCIe 4.0 x16 slot (x4 mode).

• 2 x PCIe 3.0 x1 slots for additional cards.

• Integrated Intel UHD Graphics (CPU dependent) with:

  • 1 x HDMI 2.1 port (up to 4K at 60Hz).

  • 1 x DisplayPort 1.2.

Storage

• 3 x M.2 PCIe slots (PCIe 4.0 x4) with thermal guards for high-speed NVMe drives.

• 4 x SATA 6Gb/s ports supporting RAID 0, 1, 5, and 10.

Networking & Wireless

• Intel 2.5GbE LAN for fast and reliable wired connectivity.

• Optional support for Wi-Fi module depending on revision (some models ship as Wi-Fi ready).

Audio

• Realtek HD Audio codec (ALC897/ALC1220-VB depending on revision).

• High-quality audio capacitors for clear, immersive sound output.

Connectivity & Rear I/O

• USB Ports:

  • 1 x USB 3.2 Gen 2x2 Type-C.

  • 2 x USB 3.2 Gen 2 Type-A.

  • 4 x USB 3.2 Gen 1.

  • 4 x USB 2.0.

• Rear panel includes:

  • 1 x HDMI port.

  • 1 x DisplayPort.

  • 1 x RJ-45 2.5GbE LAN port.

  • 3 x Audio jacks.

Cooling & Durability

• Advanced Thermal Design with extended heatsinks and dedicated M.2 thermal guards.

• Smart Fan 6 technology with multiple hybrid fan headers and temperature sensors for precise cooling.

• Ultra Durable construction with reinforced PCIe slots, solid pin power connectors, and multilayer PCB for longevity.

BIOS & Utilities

• Q-Flash Plus allows BIOS updates without installing CPU, RAM, or GPU.

• Modern BIOS interface for easy tuning and overclocking.

• GIGABYTE Control Center for performance optimization and RGB Fusion lighting control.

Form Factor & Build

• ATX form factor (30.5 cm x 24.4 cm).

• Sleek black PCB with subtle gaming-inspired accents and RGB Fusion support for customizable lighting.

Conclusion

The GIGABYTE Z790 GAMING X offers an ideal blend of next-generation connectivity, high-speed DDR5 memory support, PCIe 5.0 expansion, and solid thermal performance. It’s a reliable, cost-effective motherboard for building powerful and future-ready gaming systems.
