Platform & Compatibility

• Socket: LGA 1700, supporting Intel 12th - 14th Generation Core, Pentium Gold, and Celeron processors.

• Chipset: Intel B760, delivering a balance of modern I/O, overclock-friendly memory, and efficient power management without the premium cost of Z-series boards.

Memory Support

• Four DDR5 DIMM slots arranged in dual-channel mode.

• Memory rated for high frequencies via overclocking / XMP profiles; “Memory Boost” enhancements to stabilize high-rate DDR5.

• Typical maximum supported configuration around 192 GB.

Expansion & Storage

• Dual M.2 slots supporting NVMe SSDs (PCIe 4.0 ×4) for fast storage and boot performance. Some M.2 slots include thermal shields to reduce throttling.

• Multiple SATA 6 Gb/s ports for additional SSDs or traditional hard disks.

• PCIe slots: One main PCIe 4.0 ×16 slot for graphics card; additional slots (x4 / x1) for other accessories or GPU support in secondary mode.

Connectivity & Networking

• Integrated Wi-Fi 6E with support for the 6 GHz band for low-latency wireless, plus Bluetooth for peripherals.

• 2.5 Gigabit Ethernet LAN for high-speed, wired network performance.

• Rear I/O includes USB Type-C (Gen2), multiple USB 3.2/Gen1 and Gen2 ports, HDMI and DisplayPort outputs (depending on CPU IGPU), as well as audio jacks.

Power Delivery and Thermal Features

• Enhanced VRM setup (often 12+1+1 or similar phases) with strong power stages and MOSFETs to deliver stable current under load.

• Heatsinks over the VRM area and extended heatsink design for better thermal dissipation.

• Thermal pads and additional cooling features for M.2 slots to avoid thermal throttling.

• Motherboard layout includes multiple fan headers and support for chassis / CPU / pump fans for flexible cooling.

Build & User Features

• Durable ATX form factor with quality PCB (multiple layers, likely thickened copper traces) for stability and durability.

• Steel Armor or reinforced PCIe slot to reduce GPU sag and protect electrical connection.

• Utilities like “Audio Boost,” “Mystic Light” for RGB lighting, BIOS utilities for user-friendly configuration, debug LEDs, safe state recoveries.

• Extras like WiFi antenna kit, M.2 screws/guards, robust I/O shield included.

Conclusion

The MSI B760 GAMING PLUS WIFI delivers a compelling feature set for gamers and content creators who want modern standards—fast DDR5, strong storage, superior networking, and reliable power delivery—without stepping up to ultra-premium motherboards. It excels in offering value: if you're building a mid-to-high performance system where you care about speed and connectivity but can compromise on ultra extreme overclocking or redundant features, this board offers nearly everything you need and more.
