Features

Platform & CPU Support

• Socket: LGA 1700, compatible with Intel 12th, 13th, and 14th-Gen Core processors, as well as Pentium Gold and Celeron models.

• Chipset: Intel B760, which provides a balance between features and cost—good I/O and memory support without premium Z-series price.

Memory Support

• 4 DDR5 DIMM slots in dual-channel configuration.

• Maximum capacity around 256 GB.

• Strong overclocking support: memory speeds up to ~6800 MHz (OC) under the right conditions. Different configurations (1DPC/2R etc.) affect achievable speeds.

• Supports Intel XMP profiles for easier tuning.

Expansion & Graphics Slots

• One PCIe 4.0 ×16 slot for the graphics card.

• Additional PCIe 4.0 ×1 or ×1 slots (from chipset) for smaller expansion cards.

• Steel Armor reinforcement on main GPU slot to improve durability and maintain good signal integrity.

Storage & RAID Support

• Two M.2 slots, both PCIe 4.0 ×4, capable of supporting NVMe SSDs. One of them uses a thermal shield (M.2 Shield Frozr) to reduce throttling.

• Four SATA 6 Gb/s ports for additional SSDs/HDDs.

• RAID support for SATA storage (RAID 0/1/5/10).

Connectivity & I/O

• Rear I/O includes USB ports: Type-C (10 Gbps), USB 3.2 Gen-1 / Gen-2, plus USB 2.0.

• Display outputs (if CPU has iGPU): HDMI, DisplayPort (detail of versions depends on CPU). Also includes legacy VGA for wider compatibility.

• Onboard Gigabit LAN via Realtek or similar. No built-in WiFi.

• High-definition audio (7.1 channels) using Realtek ALC897 (or equivalent) codec.

Power Delivery & Thermal Design

• Decent VRM layout (digital power design) to support CPUs under load with stability.

• Heatsinks over VRM area, and M.2 shield helps dissipate heat from SSDs.

• Multiple fan headers (CPU, system) and BIOS fan controls to ensure good cooling.

On-board Features & Build Quality

• Micro-ATX form factor, fitting in smaller cases while offering key features.

• Debug LEDs (EZ-Debug) for troubleshooting POST failures.

• Good build quality with robust headers, power connectors, quality components (capacitors, chokes etc.).

• BIOS supports memory tuning, stable overclocking, power monitoring.

Conclusion

The MSI B760M-P DDR5 is an excellent motherboard for users who want modern performance without flagship pricing. It delivers strong memory overclocking, reliable storage options, stable power delivery, and solid connectivity in a compact micro-ATX form. It’s especially good for mid-range gaming, content creation, or general productivity builds. If your workload demands extreme PCIe 5.0 storage or mass GPU slots, a higher-tier board may be more appropriate—but for most users, this board provides excellent value and future-readiness.
