CPU & Chipset Support

• Socket: LGA 1700, compatible with Intel 12th, 13th, and 14th Gen Core processors, as well as Pentium Gold and Celeron.

• Chipset: Intel B760, which provides modern I/O, memory support, and features without the premium cost of Z-series boards.

Memory Support

• Two DDR4 DIMM slots, supporting dual-channel operation.

• Maximum memory capacity: 64 GB.

• Supports overclocked memory speeds (OC) up to ~4800 MHz under certain configurations; standard JEDEC speeds also supported.

Expansion & Graphics Outputs

• Expansion slots:
  • 1 × PCIe 4.0 x16 slot for a discrete GPU or primary graphics.
  • 1 × PCIe 3.0 x1 slot for expansion cards.

• Display outputs (if using a CPU with integrated graphics):
  • 1 × HDMI 1.4 (up to 4K at 30 Hz)
  • 1 × VGA (various resolutions depending on CPU integrated GPU capabilities)

Storage & RAID Support

• 1 × M.2 slot for NVMe SSDs (PCIe 4.0 x4 / SATA capable depending on model)

• 4 × SATA 6 Gb/s ports for additional SSDs/HDDs

• RAID support for SATA devices (RAID 0, 1, 5, 10)

Connectivity & I/O

• USB ports: combination of USB 2.0, USB 3.2 Gen1 Type-A on rear and front headers.

• Network: Gigabit LAN (Realtek-class) for wired connectivity.

• Audio: Realtek ALC897 codec, delivering 7.1-channel high-definition audio.

• Internal headers include fan, power/reset, front audio, and USB connectors, plus debug LEDs to assist troubleshooting.

Power Delivery & Cooling Design

• Solid digital power design (“Core Boost”) and premium layout help deliver stable CPU power.

• Heatsinks over VRMs may be present, modest but sufficient cooling expected in typical use.

• Multiple fan headers allow support for CPU plus two system fans for airflow.

Form Factor & Build, Other Features

• Form factor: Micro-ATX, size around 200 mm × 236 mm.

• Durability features like reinforced PCIe slot (“Steel Armor”) to help protect GPU installation and improve stability.

• Bios support for customization including memory profiles, fan control, and system monitoring.

• Warranty typically 3 years.

Conclusion

The MSI PRO B760M-E DDR4 is a solid mainstream motherboard for users who need reliable performance without premium flagship cost. It’s well suited for office PCs, media centers, or entry to mid-level gaming builds where features like one M.2 slot, basic I/O, and DDR4 are sufficient. If you don’t need PCIe 5.0, WiFi, or multiple high-bandwidth expansion slots, this board delivers excellent value and stability.
