GIGABYTE B760M GAMING AC DDR5
The GIGABYTE B760M GAMING AC DDR5 motherboard supports Intel 12th to 14th Gen CPUs, high-speed DDR5 memory, PCIe 4.0, dual M.2 slots, Wi-Fi, 2.5GbE LAN, and RGB Fusion, delivering reliable performance for gaming and multitasking.
Features
Key Highlights & Specifications
1. CPU & Power Delivery
-
Equipped with an LGA 1700 socket, it supports Intel 12th, 13th and 14th Gen Core, Pentium Gold, and Celeron processors.
-
Features a robust 6+2+1-phase hybrid digital VRM setup, using low-RDS(on) MOSFETs and premium chokes that deliver clean and stable power
2. Memory Support
-
Dual-channel DDR5 memory via 2 DIMM slots, supporting overclocked speeds up to 8000 MT/s (OC) and capacity up to 96 GB (48 GB per DIMM), with a few sources even stating support up to 128 GB
-
Full XMP profile support for swift overclocking
3. Expansion & Storage
-
Includes 1× PCIe 4.0 ×16 slot (with EZ-Latch quick-release design) and 1× PCIe 3.0 ×1 slot for additional cards
-
Dual M.2 slots (both support PCIe 4.0 ×4 SSDs) and 4× SATA 6 Gb/s ports, with RAID 0, 1, 5, and 10 support
4. Networking & Connectivity
-
Wired networking is handled by a Realtek 2.5GbE LAN controller
-
Wireless capabilities include Wi-Fi 802.11ac and Bluetooth 4.2, typically via an AzureWave module (RTL8821CE); some versions support Bluetooth 5.1
-
Rear I/O includes:
-
USB: 1× USB-C (USB 3.2 Gen1), multiple USB-A ports (USB 3.2 Gen1 and USB 2.0), PS/2 port
-
Display: HDMI, DisplayPort, and D-Sub — supports up to three simultaneous displays
-
5. Cooling & Fan Control
-
Incorporates Smart Fan 6, with multiple temperature sensors, hybrid fan headers, and Fan Stop functionality to suppress noise under light loads
6. BIOS & DIY Features
-
The Q-Flash Plus feature lets users update BIOS without requiring a CPU, RAM, or GPU installed
-
Full RGB customization via RGB Fusion 2.0, with support for both standard and addressable LED strips
7. Audio & Build Quality
-
High-definition audio powered by Realtek codec, supporting up to 7.1 channels and optionally S/PDIF out for enhanced sound output
8. Physical & OS Support
-
Compact Micro-ATX form factor measuring 24.4 × 22.5 cm
-
Compatible with Windows 10 and Windows 11 (64-bit)
-
Comes with a 3-year warranty, depending on the region
Specifications
| CPU | LGA1700 SOCKET SUPPORT FOR THE 14TH , 13TH AND 12TH GENERATION INTEL CORE , PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | SUPPORT FOR DDR5 UPTO 8000 MT/S (OC) |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5GBPS/1 GBPS/100 MBPS) , REALTEK RTL8821CE (PCB REV. 1.0) , WIFI 802.11a, b, g, n, ac, SUPPORTING 2.4/5 GHz DUAL BAND , BLUETOOTH 5.0 , SUPPORT FOR 11AC WIRELESS STANDARD , INTEL WIRELESS-AC 9461 (PCB REV. 1.1) , WIFI 802.11a,b,g,n,ac SUPPORTING 2.4/5 GHz DUAL BAND, BLUETOOTH 5.1 , SUPPORT FOR 11AC WIRELESS STANDARD |
| AUDIO | REALTEK AUDIO CODEC , HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT , SUPPORTING PCIe 4.0 AND RUNNING AT X16 ,1 X PCI EXPRESS X1 SLOTS , SUPPORTING PCIe 3.0 AND RUNNING AT X1 |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (SOCKET 3 M KEY , TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT) (M2A_CPU) , 1 X M.2 CONNECTOR (SOCKET 3, M KEY, TYPE 2280 PCIe 4.0 X4/X2 SSD SUPPORT (M2P_SB ) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24 PIN ATX MAIN POWER CONNECTOR , 1 X 8 PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER , 3 X SYSTEM FAN HEADERS , 1 X ADDRESSABLE LED STRIP HEADER ,1 X RGB LED STRIP HEADERS , 2 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER (FOR THE GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 MODULE ONLY ) 1 X S/PDIF OUT HEADER ,1 X SERIAL PORT HEADER , 1 X Q-FLASH PLUS BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 2 X USB 2.0/1.1 PORTS , 1 X PS/2 KEYBOARD/MOUSE PORT ,2 X SMA ANTENNA CONNECTORS (1T1R), 1 X D-SUB PORT, 1 X HDMI PORT , 1 X DISPLAYPORTS , 3 X USB 3.2 GEN 1 PORTS , 1 X USB TYPE-C PORT, WITH USB 3.2 GEN 1 SUPPORT , 1 X RJ-45 PORT , 3 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , AVAILABLE APPLICATIONS IN GCC MAY VARY BY MOTHERBOARD MODEL . SUPPORTED FUNCTIONS OF EACH APPLICATIONS MAY ALSO VARY DEPENDING ON MOTHERBOARD SPECIFICATIONS , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
