MSI PRO B760M A DDR4 WIFI
The MSI PRO B760M-A DDR4 WiFi is a micro-ATX motherboard for Intel 12th/13th/14th Gen CPUs, featuring dual-channel DDR4, PCIe 4.0 graphics, dual M.2 storage, WiFi 6E, 2.5 Gb LAN, and a durable power design.
Features
CPU & Chipset Support
-
Socket: LGA 1700 for Intel 12th, 13th, and 14th Gen Core processors as well as Pentium Gold and Celeron CPUs.
-
Chipset: Intel B760, bringing PCIe 4.0 support, fast storage, and modern connectivity in a mainstream package.
Memory Support
-
Four DDR4 DIMM slots in dual-channel configuration.
-
Maximum capacity up to 128 GB.
-
Supports high-speed DDR4 up to 5333 MHz (OC) depending on modules and configuration.
-
Intel XMP profiles supported for easy overclocking.
Expansion & Graphics Slots
-
1 × PCIe 4.0 x16 slot (reinforced) for a discrete GPU.
-
2 × PCIe 3.0 x1 slots for add-on cards.
-
Compatible with CPUs with integrated graphics or discrete GPUs.
Storage & RAID
-
2 × M.2 slots (PCIe 4.0 x4) for NVMe SSDs — one with M.2 Shield Frozr for better thermal performance.
-
4 × SATA 6 Gb/s ports for additional SSDs or HDDs.
-
RAID 0/1/5/10 support for SATA drives.
Networking & Wireless
-
Integrated WiFi 6E module with Bluetooth for modern wireless connectivity.
-
Realtek 2.5 Gb Ethernet LAN for high-speed wired connections.
Display & Rear I/O
-
HDMI and DisplayPort outputs for CPUs with integrated graphics.
-
USB: mix of USB 3.2 Gen2, Gen1, and USB 2.0 on rear panel plus front headers.
-
Audio: 7.1-channel high-definition audio via Realtek ALC897 (or similar) codec.
-
EZ Debug LEDs for quick troubleshooting.
Power Delivery & Cooling
-
Digital VRM power design ensures stable CPU performance.
-
Heatsinks over VRM and M.2 for efficient heat dissipation.
-
Multiple fan headers with BIOS/utility control for system airflow.
Form Factor & Build
-
Micro-ATX size fits easily into smaller cases without losing essential features.
-
Reinforced PCIe slot for GPU stability and quality components for long-term reliability.
-
User-friendly BIOS for tuning, fan control, and system monitoring.
Conclusion
The MSI PRO B760M-A DDR4 WiFi blends reliability, modern performance, and wireless convenience in a compact micro-ATX form factor. It’s ideal for professionals or gamers seeking DDR4 affordability, fast storage, stable power delivery, and built-in WiFi without paying for premium extras.
Specifications
| CPU | SUPPORT INTEL CORE 14TH , 13TH, 12TH GEN PROCESSORS INTEL PENTIUM GOLD AND CELERON PROCESSORS |
|---|---|
| CHIPSET | B760 |
| MEMORY | 4 X DDR5 , SUPPORTS UPTO 5333 MT/S (OC) MEMORY MODULES |
| VIDEO OUTPUT PORTS | 2 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | 1 X REALTEK RTL8125BG 2.5GBPS LAN , INTEL WI-FI 6E , SUPPORTS BLUETOOTH 5.3, FIPS, FISMA |
| AUDIO | REALTEK ALC897 CODEC , 7.1 CHANNEL HIGH DEFINITON AUDIO |
| EXPANSION SLOTS | 2 X PCI-E X16 SLOT , 1 X PCI-E X1 SLOT , PCI_E1 GEN PCIe 4.0 SUPPORTS UP TO X16 , PCI_E2 GEN PCIe 3.0 SUPPORTS UP TO X1 , PCI_E3 GEN PCIe 4.0 SUPPORTS UP TO X4 |
| STORAGE INTERFACES | 2 X M.2 , M.2_1 SOURCE (FROM CPU) SUPPORTS UP TO PCIe 4.0 X4 , SUPPORTS 2280/2260/2242 DEVICES , M.2_2 SOURCE (FROM CHIPSET) SUPPORTS 2280/2260/2242 DEVICES , 4 X SATA 6G |
| INTERNAL I/O CONNECTORS | 1 X POWER CONNECTOR(ATX_PWR) , 2 X POWER CONNECTOR(CPU_PWR) , 1 X CPU FAN , 1 X PUMP FAN , 2 X SYSTEM FAN , 2 X FRONT PANEL (JFP) , 1 X CHASSIS INTRUSION (JCI) , 1 X FRONT AUDIO (JAUD) , 1 X COM PORT (JCOM) , 2 X ADDRESSABLE V2 RGB LED CONNECTOR (JARGB_V2) , 1 X RGB LED CONNECTORS (JRGB) , 1 X TPM PIN HEADER (SUPPORT TPM 2.0) , 4 X USB 2.0 PORTS , 4 X USB 5GBPS TYPE-A PORTS , 1 X USB 5GBPS TYPE-C PORTS |
| BACK PANEL CONNECTORS | KEYBOARD/MOUSE , DISPLAY PORT , USB 3.2 GEN 1 5GBPS(TYPE-A) , 2.5G LAN , WI-FI/BLUETOOTH , AUDIO CONNECTORS , USB 2.0 , HDMI , USB 3.2 GEN 2 10GBPS (TYPE-A) |
| SIZE | MICRO ATX |
