Features

CPU & Chipset Support

• Socket: LGA1700 supporting Intel 12th and 13th Gen Core, Pentium Gold, and Celeron processors.

• Chipset: Intel Z690, optimized for high-end performance, multitasking, and productivity.

Memory Support

• Slots: Four DDR4 DIMM slots.

• Capacity: Up to 128 GB.

• Speeds: Supports DDR4 memory up to 5200 MHz (OC).

• XMP: Intel Extreme Memory Profile ready for quick and stable overclocking.

Expansion Slots

• Graphics: One PCIe 5.0 x16 slot reinforced with Steel Armor for future-ready GPUs.

• Additional Slots: One PCIe 3.0 x16 (x4) and two PCIe 3.0 x1 slots for extra cards.

Storage

• M.2: Four PCIe 4.0 x4 M.2 slots with M.2 Shield Frozr heatsinks to keep NVMe SSDs cool.

• SATA: Six SATA 6 Gb/s ports for HDDs and SSDs.

Networking

• LAN: 2.5G LAN for fast and reliable wired connectivity.

• Wireless: WiFi not built-in but supported via PCIe or USB adapters.

USB & Connectivity

• Rear I/O: USB 3.2 Gen2x2 Type-C, USB 3.2 Gen2, Gen1, and USB 2.0 ports.

• Front Panel: Additional headers for USB connectivity on compatible cases.

Display & Audio

• Video Outputs: HDMI and DisplayPort for CPUs with integrated graphics.

• Audio: 7.1-channel high-definition audio with Audio Boost for clearer sound.

Power Delivery & Cooling

• VRM Design: Robust power phases with premium chokes and capacitors for consistent power delivery and overclocking headroom.

• Cooling: Extended heatsinks, multiple fan/pump headers, and M.2 Shield Frozr for optimal thermal performance.

Form Factor & Build

• Form Factor: ATX for maximum expansion.

• Durability: Solid PCB with reinforced PCIe slots and surge protection.

• BIOS: User-friendly Click BIOS 5 for easy setup and fine-tuning.

Conclusion

The MSI PRO Z690-A DDR4 is a future-ready, high-performance motherboard offering excellent connectivity, strong power delivery, and PCIe 5.0 support. It’s ideal for power users, professionals, and gamers who prefer DDR4 memory while embracing next-generation features.
