Features

PU & Chipset Compatibility

• Socket: LGA 1700 supporting Intel 12th, 13th, and 14th Gen Core CPUs plus Pentium Gold and Celeron.

• Chipset: Intel Z790, which enables latest connectivity, higher bandwidth, and modern feature set.

Memory Support

• 4 DDR5 DIMM slots in dual-channel mode.

• Supports very high memory frequencies when overclocked, e.g. “7000+ MHz OC” in favorable configurations with one DIMM per channel etc.

• Maximum memory capacity around 256 GB.

Expansion & PCIe Slots

• Primary PCIe 5.0 ×16 slot for GPU (from CPU).

• Additional PCIe 4.0 / 3.0 slots for other cards: a PCIe 4.0 ×16 (x4 mode) plus others for add-ons.

Storage Options

• Multiple M.2 slots: some from CPU, some from chipset, supporting NVMe SSDs, and some M.2 slots support SATA mode.

• SATA 6 Gb/s ports: about six for additional storage devices.

• RAID support for SATA drives.

Networking & Wireless

• Onboard WiFi 6E module for wireless connectivity plus Bluetooth.

• Wired LAN: 2.5 Gigabit Ethernet for faster stable wired networking.

USB & I/O Features

• Rear I/O includes USB 3.2 Gen2x2 Type-C (20 Gbps) and other USB Gen2 / Gen1 / USB-A ports.

• Display outputs include HDMI and DisplayPort (depending on CPU’s integrated graphics).

Audio, Power & Cooling

• Audio: Realtek ALC897 codec, 7.1 channel audio.

• Power delivery: solid VRM configuration, designed to support high power CPUs. Cooling includes heatsinks over M.2 and MOSFET parts to help thermal performance.

Form Factor & Build

• ATX form factor: standard size for good expansion.

• Durable build, good PCB design, wired features (e.g. BIOS Flash-back, etc.).

Conclusion

The MSI PRO Z790-P WIFI DDR5 is a well-rounded motherboard that delivers high-speed performance, excellent storage options, and modern connectivity. It’s ideal for users who want to build a powerful Intel system using DDR5, needing strong networking and multiple SSDs without stepping up to ultra-premium cost. If you value performance per dollar, future readiness, and stable power delivery, this board is a smart choice.
