GIGABYTE B550 AORUS ELITE V2
The Gigabyte B550 AORUS ELITE V2 is a high-performance ATX motherboard for AMD AM4 Ryzen processors. It features a 12+2 digital VRM design, PCIe 4.0 support, dual M.2 slots, 2.5GbE LAN, and robust thermal solutions.
Features
CPU & Chipset Support
-
Socket: AM4
-
Chipset: AMD B550
-
Compatibility: Supports 3rd Gen AMD Ryzen processors, including Ryzen 5000 series.
Memory
-
Slots: 4 x DDR4 DIMM slots (dual-channel)
-
Capacity: Up to 128GB
-
Speeds: Supports DDR4 memory speeds up to 4733MHz (OC).
Storage & Expansion
-
M.2 Slots: 2 x PCIe 4.0/3.0 x4 M.2 slots (one with thermal guard)
-
SATA Ports: 4 x SATA 6Gb/s ports
-
PCIe Slots: 1 x PCIe 4.0 x16 slot, 2 x PCIe 3.0 x16 slots (x4 mode), 2 x PCIe 3.0 x1 slots.
Networking & Connectivity
-
LAN: Realtek 2.5GbE LAN
-
USB Ports: 2 x USB 3.2 Gen 2, 3 x USB 3.2 Gen 1, 2 x USB 2.0 Type-A ports on rear I/O; additional headers for front panel connectivity.
-
Video Outputs: HDMI 2.1, DisplayPort 1.2 (dependent on CPU with integrated graphics).
Audio
-
Codec: Realtek ALC1200
-
Channels: 8-channel HD audio
-
Features: WIMA capacitors for enhanced audio quality.
Thermal & Power Design
-
VRM Design: 12+2 digital VRM phases
-
Heatsinks: Enlarged surface heatsinks with 5 W/mK thermal conductivity pads
-
M.2 Thermal Guard: Prevents thermal throttling of M.2 SSDs.
Lighting & Aesthetics
-
RGB Fusion 2.0: Supports RGB lighting with addressable LED strips.
-
Design: Black PCB with AORUS branding and subtle RGB accents.
Additional Features
-
BIOS Flashback: Q-Flash Plus for BIOS updates without CPU installation.
-
Fan Headers: Multiple fan headers with Smart Fan 5 technology for optimized cooling.
Conclusion
The Gigabyte B550 AORUS ELITE V2 offers a balanced mix of performance, aesthetics, and features suitable for gamers and PC enthusiasts. Its robust VRM design, PCIe 4.0 support, and advanced thermal solutions ensure reliable performance for demanding applications and workloads. While it lacks integrated Wi-Fi, the inclusion of 2.5GbE LAN and multiple USB ports provides ample connectivity options. Overall, it's a solid choice for users seeking a feature-rich motherboard without breaking the bank.
Specifications
| CPU | AMD SOCKET AM4, SUPPORT FOR:AMD RYZEN 5000 SERIES/RYZEN 5000 G-SERIES/RYZEN 4000 G-SERIES , RYZEN 3000 SERIES AND RYZEN 3000 G-SERIES PROCESSORS |
|---|---|
| CHIPSET | B550 |
| MEMORY | 4 X DDR4 DIMM SOCKETS SUPPORTING UP TO 128GB(32 GB SINGLE DIMM CAPACITY) OF SYSTEM MEMORY , SUPPORT FOR DDR4 4733(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4133(OC) / 4000(OC) / 3866(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3400(OC) / 3200 / 2933 / 2667 / 2400 / 2133 MHz MEMORY MODULES |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5 GBIT/1 GBIT/ 100 MBIT ) |
| AUDIO | REALTEK ALC1200 CODEC HIGH DEFINITION AUDIO 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT (PCIEX16), 1 X PCI EXPRESS X16 SLOT (PCIEX2) , 1 X PCI EXPRESS X16 SLOT (PCIEX1_2), 1 X PCI EXPRESS X1 SLOT (PCIEX1_1) |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (M2A_CPU), INTERGRATED IN THE CPU , SUPPORTING SOCKET 3 M KEY, TYPE 2242/2260/2280/22110 SSD , 1 X M.2 CONNECTOR (M2B_SB), INTERGRATED IN THE CHIPSET, SUPPORTING SOCKET 3 , M KEY TYPE 2242/2260/2280/22110 SSD , 4 X SATA 6GB/S CONNECTORS , INTEGRATED IN THE CHIPSET , |
| INTERNAL I/O CONNECTORS | 1 X 24-PIN ATX MAIN POWER CONNECTOR , 1 X 8-PIN ATX 12V POWER CONNEECTOR , 2 X M.2 SOCKET 3 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X CPU FAN HEADER , 1 X WATER COOLING CPU FAN HEADER , 3 X SYSTEM FAN HEADERS , 1 X CPU COOLER LED STRIP/RGB LED STRIP HEADER , 2 X ADDRESSABLE LED STRIP HEADER , 2 X RGB LED STRIP HEADERS , 1 X FRONT PANEL HEADERS , 1 X FRONT PANEL AUDIO HEADER , 1 X USB TYPE-C PORT , WITH USB 3.2 GEN 1 SUPPORT , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE (TPM) HEADER (2X6 PIN, FOR THE GC-TPM2.0_S MODULE ONLY ) , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 1 X DISPLAYPORT , 1 X HDMI PORT , 2 X USB 3.2 GEN 2 TYPE-A/USB 3.2 GEN 1 PORTS (RED) , 3 X USB 3.2 GEN 1 PORTS , 2 X USB 2.0/1.1 PORTS , 1 X Q-FLASH PLUS BUTTON , 1 X RJ-45 PORT , 1 X OPTICAL S/PDIF OUT CONNECTOR , 5 X AUDIO JACKS |
| SIZE | ATX |
| UNIQUE FACTORS | BIOS , EASYTUNE , RGB FUSION , SMART BACKUP , SYSTEM INFORMATION VIEWER , SUPPORT FOR Q-FLASH PLUS , SUPPORT FOR Q-FLASH |
