GIGABYTE B650 DS3H
The GIGABYTE B650 DS3H motherboard supports AMD Ryzen AM5 series processors, featuring DDR5 memory, PCIe 5.0, and reliable connectivity. Perfect for gamers, content creators, and PC builders seeking stable, high-performance, future-ready systems.
Features
The GIGABYTE B650 DS3H is a high-performance motherboard designed for AMD Ryzen 7000-9000 series processors. With PCIe 5.0 support, DDR5 memory compatibility, and multiple storage options, it delivers fast and stable performance. Robust power delivery and efficient thermal design ensure reliability under heavy workloads, making it ideal for gaming, content creation, and professional PC builds.
Key Features and Specifications:
-
CPU Support: AMD Ryzen 7000-9000 series processors (AM5 socket)
-
Chipset: AMD B650 chipset with PCIe 5.0 support for graphics and storage
-
Memory: Supports up to 128GB DDR5 RAM with high-speed overclocking
-
Expansion Slots:
-
1 x PCIe 5.0 x16 slot
-
1 x PCIe 4.0 x16 slot
-
Additional PCIe 4.0 x1 slots
-
-
Storage:
-
4 x SATA III ports
-
3 x M.2 slots with PCIe 5.0/4.0 support
-
-
Networking: Intel Gigabit LAN for reliable wired connectivity
-
Audio: 7.1-channel HD audio with premium capacitors for immersive sound
-
USB Ports: USB 3.2 Gen 2, USB Type-C, and USB 2.0 ports for peripherals
-
Thermal Design: Efficient heatsinks and multiple fan headers for stable cooling
-
BIOS: User-friendly BIOS interface with overclocking, system monitoring, and tuning options
Conclusion:
The GIGABYTE B650 DS3H combines DDR5, PCIe 5.0, and robust connectivity in a reliable motherboard. It is ideal for gamers, creators, and PC builders seeking stable, high-performance, future-ready systems.
Specifications
| CPU | AMD SOCKET AM5, SUPPORT FOR AMD RYZEN 7000 / RYZEN 8000 / RYZEN 9000 SERIES PROCESSORS |
|---|---|
| CHIPSET | B650 |
| MEMORY | SUPPORT FOR DDR5 UP TO 8000(OC) MT/s MEMORY MODULES , 4 X DDR5 DIMM SOCKETS SUPPORTING UP TO 256GB (64GB SINGLE DIMM CAPACITY) OF SYSTEM MEMORY |
| VIDEO OUTPUT PORTS | 1 X HDMI PORT , 2 X DISPLAYPORT |
| LAN + WIFI + BLUETOOTH | REALTEK 2.5GBE LAN CHIP (2.5 GBPS/1 GBPS/100 MBPS) |
| AUDIO | REALTEK AUDIO CODEC HIGH DEFINITION AUDIO , 2/4/5.1/7.1-CHANNEL |
| EXPANSION SLOTS | 1 X PCI EXPRESS X16 SLOT (PCIEX16) , 1 X PCI EXPRESS X1 SLOT , SUPPORTING PCIe 3.0 AND RUNNING AT X1 (PCIEX1) |
| STORAGE INTERFACES | 1 X M.2 CONNECTOR (M2A_CPU) , 1 X M.2 CONNECTOR (M2B_CPU) , 4 X SATA 6GB/S CONNECTORS |
| INTERNAL I/O CONNECTORS | 1 X 24-PIN ATX MAIN POWER CONNECTOR , 1 X 8-PIN ATX 12V POWER CONNECTOR , 1 X CPU FAN HEADER , 3 X SYTEM FAN HEADERS , 1 X ADDRESSABLE LED STRIP HEADERS , 1 X RGB LED STRIP HEADERS , 2 X M.2 SOCKET 2 CONNECTORS , 4 X SATA 6GB/S CONNECTORS , 1 X FRONT PANEL HEADER , 1 X FRONT PANEL AUDIO HEADER , 1 X USB TYPE-C HEADER , 1 X USB 3.2 GEN 1 HEADER , 2 X USB 2.0/1.1 HEADERS , 1 X TRUSTED PLATFORM MODULE HEADER , 1 X SERIAL PORT HEADER ,1 X RESET BUTTON , 1 X RESET JUMPER , 1 X CLEAR CMOS JUMPER |
| BACK PANEL CONNECTORS | 4 X USB 2.0/1.1 PORTS , 1 X PS/2 KEYBOARD/MOUSE PORT , 2 X DISPLAY PORTS , 1 X HDMI PORT , 1 X USB 3.2 GEN 2 TYPE-A PORT (RED) , 1 X USB TYPE-C PORT , 1 X Q-FLASH PLUS BUTTON , 1 X RJ-45 PORT , 2 X USB 3.2 GEN 1 PORTS , 3 X AUDIO JACKS |
| SIZE | MICRO ATX |
| UNIQUE FACTORS | SUPPORT FOR GIGABYTE CONTROL CENTER (GCC) , SUPPORT FOR Q-FLASH , SUPPORT FOR Q-FLASH PLUS |
